LG CreateBoard

A New Level of Classroom with
LG CreateBoard

Various Teaching Templates
LG CreateBoard offers a variety of educational templates and teaching tools such as a ruler, table, and sticky notes, allowing for active engagement by students and enabling intuitive classes.
Editing images and videos becomes easy with LG CreateBoard, and created resources can be easily shared with others through QR codes.

Multi-touch
LG CreateBoard can simultaneously detect up to 40 points for multi-touch functionality.
This creates a lifelike board touch experience, helping students easily become accustomed and truly engage in classes. This leads to the maximum concentration and organic engagement of students.

* A max of 32 points are recognized in the Android environment,
and a max of 40 points are detected in the Windows environment.
* Up to 10 points can be recognized in the writing app.

Specifications:

    Panel
    Screen Size    55"
    Panel Technology    VA
    Back Light Type    Direct
    Aspect Ratio    16 : 9
    Native Resolution    3,840 × 2,160 (UHD)
    Refresh Rate    60 Hz
    Brightness    440 nit (w/o Glass Max.), 390 nit (w/o Glass Typ.)
    Contrast Ratio    1,200 : 1
    Color gamut    NTSC 72%
    Viewing Angle (H x V)    178 × 178
    Color Depth    10 bit (8 bit + FRC)
    Response Time    8 ms
    Surface Treatment (Haze)    25%
    Lifetime    50,000hrs (L30)
    Operation Hours (Hours / Days)    16 / 7
    Portrait / Landscape    No / Yes

    Mechanical Specification
    Bezel Color    Black
    Bezel Width (T / R / L / B)    18 / 18 / 18 / 45 mm
    Weight (Head)    26.1 kg
    Packed Weight    34.5 kg
    Monitor Dimensions (W × H × D)    1,271 × 774 × 87 mm
    Carton Dimensions (W × H × D) (Box Outer Size)    1,401 × 859 × 220 mm
    Handle    Yes
    VESA™ Standard Mount Interface    400 × 200 mm

    Environment Conditions
    Operation Temperature    0 to 40°C
    Operation Humidity    10% to 90% RH

    Power
    Power Supply    100-240 V ~, 50/60 Hz, 3.5 A
    Power Type    Built-In Power

    Power Consumption
    Typ./Max.    170 / 395 W
    DPM    0.5 W↓
    Power off    0.5 W↓
    BTU (British Thermal Unit)    580 BTU/Hr (Typ.), 1,348 BTU/Hr (Max.)

    Certification
    Safety    CB / NRTL
    EMC    FCC Class "A" / CE / KC
    ErP / Energy Star    Yes / Yes

    OPS Compatibility
    OPS Type Compatible    Yes (Slot)
    OPS Power Built In    Yes

    Software Compatibility
    LG ConnectedCare    Yes
    LG ConnectedCare DMS    Yes

    Connectivity
    Input    HDMI (3, HDCP 2.2), RGB (VGA), Audio In, RS-232C In, RJ45 (LAN), USB 3.0 Type A (4), USB 2.0 Type A, USB Type C (USB-PD, DP-Alt)
    Output    HDMI Out, Audio Out (1, Optical 1 (SPDIF)), Touch USB (2), RJ45 (LAN)

Sound
Speaker Yes (15W × 2)

Language
English, Denmark, Finnish, German, Korean, Norwegian, Polski, Portugues (Europe), Portugues (Brazil), Romanian, Spanish, Swedish, Hungarian, Thai

    Touch
    Available Object Size for Touch    Ø2 mm↑
    Response Time    ≤5 ms
    Accuracy    ±1 mm
    Interface    USB 2.0
    Protection Glass Thickness    3 T (Anti-Glare)
    Protection Glass Transmission    88%
    Operating System Support    Windows 7 / 8 / 10 / Linux / Mac / Android (Supports one point touch on Linux / Mac)
    Multi Touch Point    Max. 40 Points

    Android System
    SoC    Quad Core A55
    GPU    Mali G52MP2
    Internal Memory    32 GB
    RAM    4 GB
    Wi-Fi    802.11a/b/g/n/ac/ax (Wi-Fi 6)
    LAN    Gigabit LAN
    Bluetooth    Bluetooth 5.0

Key Feature
Internal Memory (32 GB), Built-In Wi-Fi (Slot Type), Auto Brightness Sensor, Power Indicator, webOS ver. (Android 11.0), Background Image (Booting Logo Image), Multi-screen (PIP / PBP, External Source), Screen Share (LG CreateBoard Share), Power (Smart Energy Saving, Wake on LAN)
