Интерактивен дисплей Philips 75BDL3152E/00, 74.5" (189.23 cm), 4K/UHD VA сензорен дисплей, HDMI, VGA, USB, USB-C, RS232, Wi-Fi, Bluetooth, LAN

Signage Solutions Collaboration Display

75BDL3152E/00

Interactive education display

This interactive display maximises engagement and inspires collaboration with up to 40 touchpoints. Powered by Android 13 and with toughened anti-glare and anti-reflection glass, it's made to withstand heavy daily use in busy environments.



• 75"
• Powered by Android
• Multi-touch





OPS slot allows PC embedding without cabling

Integrate a full-power PC or Android-powered CRD module directly into your Philips Professional Display. The OPS slot contains all of the connections you need to run your slot-in solution, including a power supply.

Android SoC for seamless software and app integration

Our integrated Android 13 OS has been specially developed to bring a next-level secure professional System on Chip. Save your favourite apps and software directly into the display or choose from the large library of Android apps.

Anti-glare toughened glass

Anti-glare, anti-reflection, 7 MoH hardness.

PPDS Wave-ready for remote display management and control

Your PPDS Wave-ready display enables you to manage and maintain this device remotely, wherever you are, whenever you choose. This evolutionary cloud platform puts you fully in control, with simplified installation and setup, monitoring and controlling displays, upgrading firmware, managing central content needs and setting power schedules — saving you time, energy and environmental impact.

Built-in ambient light sensor

Built-in ambient light sensors contribute to energy savings by automatically adjusting the screen brightness to the surrounding lighting conditions.

Palm rejection

Palm rejection for enhanced precision.

Multi-touch technology capable of 40 touchpoints

Create a memorable interactive experience with up to 40 touchpoints at the same time for slick, agile lessons or brainstorming sessions. Perfect for collaborative and co-creation applications, this display connects your audience with any content. Offering enhanced user friendliness with eraser functionality, palm rejection and tip-size recognition.

Advanced IR touch

Advanced 0-gap IR touch with smaller, shallower bezels.

Wireless presentations

Philips ScreenShare makes it easy for teachers and students to wirelessly share their screens from their own device, whatever the operating system, via the browser or their favourite apps onto the Philips Interactive Collaboration display.

Cast directly from any device

Teachers, students or employees can cast directly from their device with AirPlay, Google Cast and Miracast.

Whiteboard application

The embedded whiteboard application enables seamless collaboration and brainstorming directly on the display.



Technical Specifications

• Connectivity

  Audio output

  • 3.5 mm Mini Jack (x 1)
  • SPDIF

  Video input

  • HDMI 2.0 (x 3)
  • VGA (Analogue D-Sub) (x 1)
  • USB-C (up to 65 W)
  • USB 2.0 (x 1)
  • USB 3.0 (x 4)

  Audio input

  3.5 mm mini jack (x 1)

  Other connections

  • OPS
  • micro SD
  • USB-B (x 2)

  External control

  • RS232C (in) D-Sub9
  • RJ45 x 2

  Bluetooth

  BT5.2

• Picture/Display

  Diagonal screen size (metric)

  189.3  cm

  Diagonal screen size (inch)

  74.5  inch

  Aspect ratio

  16:9

  Panel resolution

  3840 x 2160

  Pixel pitch

  0.42975 (H) x 0.42975 (V) [mm]

  Optimum resolution

  3840 x 2160 @ 60 Hz

  Brightness

  400  cd/m²

  Display colours

  1.07 B

  Contrast ratio (typical)

  5500:1

  Response time (typical)

  6.5  ms

  Viewing angle (horizontal)

  178  degree

  Viewing angle (vertical)

  178  degree

  Picture enhancement

  • 3/2 - 2/2 motion pull down
  • 3D Combfilter
  • Motion compens. deinterlacing
  • Progressive scan
  • 3D MA deinterlacing
  • Dynamic contrast enhancement

  Panel technology

  VA

  Operating system

  Android 13

  OS UI resolution

  1920 x 1080 @ 60 Hz

• Convenience

  Placement

  Landscape (16/7)

  Screen-saving functions

  Pixel Shift, Low Brightness

  Keyboard control

  Lockable

  Remote control signal

  Lockable

  Other convenience

  Carrying handles

  Network controllable

  • RS232
  • RJ45

• Sound

  Built-in speakers

  2 x 16 W

• Power

  Mains power

  100 ~ 240 VAC, 50/60 Hz

  Consumption (Typical)

  155  W

  Standby power consumption

  <0.5 W

  Power Saving Features

  Smart Power

  Energy Label Class

  G

• Supported Display Resolution

  Video formats

  • 480i, 60 Hz
  • 480p, 60 Hz
  • 720p, 50, 60 Hz
  • 1080i, 50, 60 Hz
  • 1080p, 50, 60 Hz
  • 2160p, 30, 60 Hz

• Dimensions

  Set Width

  1709.4  mm

  Set Height

  1020.2  mm

  Set Depth

  85.4  mm

  Set Width (inch)

  67.30  inch

  Set Height (inch)

  40.17  inch

  Wall Mount

  800 x 400 mm, M8

  Set Depth (inch)

  3.36  inch

  Bezel width (L/R, T/B)

  16.6 mm (L/R/T)/45.0 mm (B)

• Weight

  Product with packaging (kg)

  62.5  kg

  Product with packaging (lb)

  137.79  lb

  Product without stand (kg)

  51.4  kg

  Product without stand (lb)

  113.32  lb

• Operating conditions

  Altitude

  0 ~ 5000 m

  Temperature range (operation)

  0 ~ 40  °C

  MTBF

  30,000  hour(s)

  Temperature range (storage)

  -20~60  °C

  Humidity range (operation)[RH]

  10–90% (without condensation)

  Humidity range (storage) [RH]

  10–90% (without condensation)

• Multimedia Applications

  USB Playback Video

  • H.263
  • H.264
  • H.265
  • MPEG1/2
  • MPEG4
  • VP8

  USB Playback Picture

  • BMP
  • JPEG
  • PNG

  USB Playback Audio

  • AAC
  • MPEG
  • HEAAC

• Internal Player

  CPU

  Quad-Core Cortex A55

  GPU

  Multi-Core Mali-G52

  Memory

  4 GB RAM

  Storage

  32 GB eMMc

  Wi-Fi

  2.4/5 GHz
