The Ultimate Weapon in Gaming:
The Red Devil emerges as the unparalleled force in gaming, pushing performance to its absolute peak. Powered by AMD's cutting-edge RDNA™ 4 architecture and equipped with PowerColor's advanced, whisper-quiet cooling system, it delivers exceptional performance and immersive gameplay. At its core lies the Hellstone, a breathtaking design element where vibrant RGB lighting pulses with an otherworldly glow, embodying fiery power and precision. This symbolic feature not only illuminates but represents the Red Devil’s boundless strength, leading gamers through the darkness to ultimate victory.
Engineered for Triumph:
The PowerColor Red Devil RX 9070 Series is a gaming powerhouse built to dominate. With an enhanced triple fan cooling system, 7 x 6φ heatpipes threading through its robust heatsink, and a premium copper plate ensuring direct contact with the GPU and VRAM, heat dissipation is lightning fast. Its premium phase VRM design, backed by high-quality PCBs, and DrMOS, guarantees unmatched overclocking, stability and cooling efficiency. The Red Devil is your ultimate companion for gaming victory—unleash its power and conquer every challenge.
Specifications
Stream Processor
4096 Units
Video Memory
16GB GDDR6
Memory Speed
20.0 Gbps
Memory Interface
256-bit
Engine Clock(OC)
up to 2520MHz(Game)
up to 3060MHz(Boost)
Engine Clock(STD/Silent)
up to 2460MHz(Game)
up to 3010MHz(Boost)
Bus Standard
PCIE 5.0 x16
Standard Display Connectors
1 x HDMI 2.1b，3 x DisplayPort 2.1a (only 2x simultaneous DP2.1 connections can be supported)
DirectX Support
12
OpenGL
4.6
AMD Eyefinity Technology
Support
AMD Stream Technology
Support
AMD Smart Access Memory
Support
Maximum Resolution
DisplayPort: 7680×4320
HDMI: 7680×4320
Power Specs + Board Dimensions:
Board Dimensions
340mm*132mm*69mm
352mm*149mm*69mm (with bracket)
Slot
3
Minimum System Power requirement (W)
900W
Extension Power Connector
Three 8-pin PCI Express Power connectors
Notes
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
Boost Clock is the maximum frequency achievable on the GPU running a burstyworkload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to thermal conditions and variation in applications and workloads.
Recommended power supply for AMD Radeon RX 9070 XT graphics card is minimum 900W or greater power supply with 12V output > 75A. Minimum recommended system power supply wattage is based on a PC configured with an AMD Ryzen 9 7950X processor plus typical power requirements of other system components. Your system requirements may differ.
Виж още Видео карти PowerColor
Виж всички Видео карти в категорията
The Red Devil emerges as the unparalleled force in gaming, pushing performance to its absolute peak. Powered by AMD's cutting-edge RDNA™ 4 architecture and equipped with PowerColor's advanced, whisper-quiet cooling system, it delivers exceptional performance and immersive gameplay. At its core lies the Hellstone, a breathtaking design element where vibrant RGB lighting pulses with an otherworldly glow, embodying fiery power and precision. This symbolic feature not only illuminates but represents the Red Devil’s boundless strength, leading gamers through the darkness to ultimate victory.
Engineered for Triumph:
The PowerColor Red Devil RX 9070 Series is a gaming powerhouse built to dominate. With an enhanced triple fan cooling system, 7 x 6φ heatpipes threading through its robust heatsink, and a premium copper plate ensuring direct contact with the GPU and VRAM, heat dissipation is lightning fast. Its premium phase VRM design, backed by high-quality PCBs, and DrMOS, guarantees unmatched overclocking, stability and cooling efficiency. The Red Devil is your ultimate companion for gaming victory—unleash its power and conquer every challenge.
Specifications
Stream Processor
4096 Units
Video Memory
16GB GDDR6
Memory Speed
20.0 Gbps
Memory Interface
256-bit
Engine Clock(OC)
up to 2520MHz(Game)
up to 3060MHz(Boost)
Engine Clock(STD/Silent)
up to 2460MHz(Game)
up to 3010MHz(Boost)
Bus Standard
PCIE 5.0 x16
Standard Display Connectors
1 x HDMI 2.1b，3 x DisplayPort 2.1a (only 2x simultaneous DP2.1 connections can be supported)
DirectX Support
12
OpenGL
4.6
AMD Eyefinity Technology
Support
AMD Stream Technology
Support
AMD Smart Access Memory
Support
Maximum Resolution
DisplayPort: 7680×4320
HDMI: 7680×4320
Power Specs + Board Dimensions:
Board Dimensions
340mm*132mm*69mm
352mm*149mm*69mm (with bracket)
Slot
3
Minimum System Power requirement (W)
900W
Extension Power Connector
Three 8-pin PCI Express Power connectors
Notes
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
Boost Clock is the maximum frequency achievable on the GPU running a burstyworkload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to thermal conditions and variation in applications and workloads.
Recommended power supply for AMD Radeon RX 9070 XT graphics card is minimum 900W or greater power supply with 12V output > 75A. Minimum recommended system power supply wattage is based on a PC configured with an AMD Ryzen 9 7950X processor plus typical power requirements of other system components. Your system requirements may differ.
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Видео карти PowerColor
Виж всички Видео карти в категорията
Технически характеристики
| GPU производител: | AMD Radeon |
|---|---|
| Капацитет: | 16 GB |
| Тип памет на видеокарта: | GDDR6 |
| Битове (BUS памет): | 256 Bit |
| Интерфейс: | DP HDMI |
