MAG A520M VECTOR WIFI
- Supports AMD Ryzen™ 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen™ 5 3400G & Ryzen™ 3 3200G) and AMD Ryzen™ 4000 G-Series desktop processors
- Supports DDR4 Memory, up to 4600(OC) MHz
- Extended Heatsink Design: Leading heatsink design, extended for maximum cooling and performance
- Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
- M.2 Shield Frozr: Strengthened built-in M.2 thermal solution. Keeps M.2 SSDs safe while preventing throttling, making them run faster
- Core Boost: With premium layout and digital power design to support more cores and provide better performance
- 2oz Thickened Copper PCB: An enhanced PCB design improves heat dissipation and performance reliability
- Audio Boost: Reward your ears with studio grade sound quality
- Dragon Center: A brand new software which integrates all MSI exclusive tools with user friendly user interface
Specifications:
Model Name MAG A520M VECTOR WIFI
CPU Support Support 3rd Gen AMD Ryzen™ Desktop Processors and AMD Ryzen™ 4000 G-Series Desktop Processors
CPU Socket AMD Socket AM4
Chipset AMD A520 Chipset
Graphics Interface 1x PCI-E 3.0 x16 slot
Display Interface DisplayPort, HDMI – Requires Processor Graphics
Memory Support 2 DIMMs, Dual Channel DDR4-4600MHz (OC)
Expansion Slots 2x PCI-E 3.0 x1 slots
Storage 1x M.2 Gen3 x4 slot, 4x SATA 6Gb/s ports
USB Ports 6x USB 3.2 Gen 1 5Gbps (Type-A) + 6x USB 2.0
LAN Realtek® RTL8111H Gigabit LAN
Wireless / Bluetooth Intel® Wireless-AC 3168, Bluetooth 4.2
Audio 8-Channel (7.1) HD Audio with Audio Boost
Виж още Дънни платки за AMD процесори MSI
Виж всички Дънни платки за AMD процесори в категорията
Технически характеристики
Процесор сокет: | AM4 |
---|---|
Чипсет: | A520 |
Поддържана памет: | DDR4 |
Брой слотове за RAM памет: | 2 |
Storage интерфейси: | SATA 6Gbit/s, M.2 |
RAID: | Да |
Безжични мрежи: | 802.11ac |
Bluetooth: | Да |
Видео слот: | PCI-E |
Multi-Graphics технология: | Няма |
Видео изход: | DP HDMI |
Форм фактор: | Micro ATX |
Видеокарта: | Вградена |
