Мини компютър Barebone Intel NUC 7 Home Mini PC NUC7i3BNHXF, двуядрен Kaby Lake Intel Core i3-7100U 2.4GHz, 4GB DDR4 RAM, без твърд диск(2x 2.5"), Wi-Fi & Bluetooth 4.2, Lan1000, 1x M.2 slot, 1x HDMI, 1x USB Type C, 4x USB 3.0

Intel NUC 7 Home Mini PC
NUC7i3BNHXF


Technical Specifications

Essentials
Code Name
Products formerly Baby Canyon

Board Form Factor
UCFF (4" x 4")

Socket
Soldered-down BGA

Internal Drive Form Factor
M.2 and 2.5" Drive

# of Internal Drives Supported
2

Lithography
14

TDP
15.0 W

DC Input Voltage Supported
12-19 VDC

Pre-Installed Operating System
Windows 10, 64-bit*

Processor Included
Intel® Core™ i3-7100U Processor

Supplemental Information
Embedded Options Available
No

Description
Other features: 16GB Intel® Optane™ Memory M.2 module pre-installed, 1TB HDD, Windows® 10 x64 Home, includes USB 3.1 Gen 2 (10Gbps) and DP 1.2 via USB-C; also includes microSDXC card slot, dual microphones

Memory & Storage
Pre-Installed Memory
1x 4GB DDR4-2400

Max Memory Size (dependent on memory type)
32 GB

Memory Types
DDR4-2133 1.2V SO-DIMM
Max # of Memory Channels
2

Max Memory Bandwidth
34.1 GB/s

Max # of DIMMs
2

ECC Memory Supported ‡
No

Graphics Specifications
Integrated Graphics ‡
Yes

Graphics Output
HDMI 2.0a; USB-C (DP1.2)
# of Displays Supported ‡
3

Expansion Options
PCI Express Revision
Gen3

PCI Express Configurations ‡
M.2 slot with PCIe x4 lanes
Removable Memory Card Slot

Micro SDXC with UHS-I support
M.2 Card Slot (storage)
22x42/80

I/O Specifications
# of USB Ports
6

USB Revision
2.0, 3.0

USB 2.0 Configuration (External + Internal)
0 + 2

USB 3.0 Configuration (External + Internal)
2B 2F + 0

Total # of SATA Ports
2

Max # of SATA 6.0 Gb/s Ports
2

Audio (back channel + front channel)
7.1 digital (HDMI mDP); L+R+mic (F)

Integrated LAN
10/100/1000

Integrated Wifi
Intel® Wireless-AC 8265 + Bluetooth 4.2

Integrated Bluetooth
Yes

Consumer Infrared Rx Sensor
Yes

Additional Headers
CEC, 2x USB2.0, FRONT_PANEL

Package Specifications
Low Halogen Options Available
See MDDS

Advanced Technologies
Intel® Optane™ Memory Supported ‡
Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes

Intel® vPro Technology ‡
No

TPM
No

Intel® HD Audio Technology
Yes

Intel® Rapid Storage Technology
Yes

Intel® Virtualization Technology (VT-x) ‡
Yes

Intel® Platform Trust Technology (Intel® PTT)
Yes

Security & Reliability
Intel® AES New Instructions
Yes
