True WiFi 6
The WAX510D is truly the next generation of wireless (WiFi 6) AP, especially for businesses looking to strike the right balance between performance and budget. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO, which can’t be found in the earlier releases of 802.11ax products. The WAX510D boasts an impressive quad-core processor with 2 network accumulators to guarantee that a smooth and consistently fast service is provided to each client at all times.
The smartest choice
The WAX510D is not only efficient at delivering impressive high speeds with smooth and consistent delivery to wireless clients, but also it’s efficient on power. The WAX510D can deliver its impressive performance while keeping the consumption of PoE within the PoE+ standard, so that you can enjoy the latest WiFi 6 technology offering without the need to invest in upgrading your traditional switching architecture.
Specifications
Product name
Description: 802.11ax (WiFi 6) Dual-Radio Unified Access Point
Wireless
Standard: IEEE802.11 ax / ac / n / g / b / a
MIMO: MU-MIMO
Wireless speed: 2.4GHz: 575Mbps, 5GHz: 1200Mbps
Frequency band
2.4 GHz (IEEE 802.11 b / g / n)
Europe (ETSI): 2.412 to 2.472 GHz
5 GHz (IEEE 802.11 a / n / ac)
5.725 to 5.850 GHz
European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz
RF Design
Antenna type: Dual optimized Antenna
Antenna gain:
2.4GHz: Peak Gain 5dBi
5GHz: Peak Gain 6dBi
Minimum Receive sensitivity: Min. Rx sensitivity up to -101 dBm
WLAN feature
Band Steering: Yes
WDS: Future suppoet
Mesh AP (By License): Future Support
Mesh AP for multiple SSID with VLAN: Future Support
Smart mesh: Future Support
Fast roaming: Pre-authentication, PMK caching and 802.11r
DCS (Auto Channel): Yes
Load balancing: Yes
Security
Wireless Security
- WPA
- WPA-PSK
- WPA-Enterprise (WPA / WPA2 / WPA3)
Access management
- L2-isolation
- MAC filtering
- Rogue AP detection
- EAP
- IEEE 802.1X
- RADIUS authentication
Networking
IPv6: Yes
VLANs: Yes
WMM: Yes
U-APSD: Yes
DiffServ marking: Yes
Physical Specifications
Dimensions (WxDxH) (mm / in.): 180 x 180 x 39 / 7.09 x 7.09 x 1.54
Weight (g / lb.): 453g / 1
Packing Dimensions (WxDxH) (mm / in.): 229 x 216 x 64 / 9.02 x 8.5 x 2.52
Weight (g / lb.): 770g / 1.7
Physical Interfaces
Ethernet port: 1 x 10/100 / 1000M LAN
Power: PoE (802.3) at: power draw 17 W
DC input: 12 VDC 1.5A
Виж още Аксеспойнт/Репитер Безжични ZyXEL
Виж всички Аксеспойнт/Репитер Безжични в категорията
Документация
Технически характеристики
Тип: | Аксес пойнт |
---|---|
Монтаж: | За вътрешен монтаж |
Безжична скорост: | 1700 Mbps |
Wi-Fi Стандарт: | Wi-Fi 6 (802.11ax) |
Честота: | 2.4 & 5 GHz |
Антени: | 2 Вътрешни |
dBi на антена/и: | 6 |
PoE: | In |
Интерфейс: | 1x 1000 |
Други: | Няма |
