Точка за достъп ZyXEL NWA110AX, 2.4GHz (575Mbps)/5.0GHz (1200Mbps), 1x 10/100/1000M LAN, 802.11ax, PoE+, 2x вътрешни антени

True WiFi 6

The NWA110AX is truly the next generation of wireless (WiFi 6) AP for businesses looking for a most economical upgrade path to 11ax. Its built-in 2nd Generation WiFi 6 (Qualcomm 802.11ax 2.0) chipset allows the access point to take advantage of the full range of WiFi 6 technologies including uplink OFDMA and MU-MIMO which can’t be found in earlier releases of 802.11ax products

Simpler upgrade path

The NWA110AX has been designed to be highly efficient in PoE budget, allowing for an easy upgrade path for those wishing to experience all that WiFi 6 has to offer without the need to upgrade existing PoE+ switches

Specifications

Product name
802.11ax (WiFi 6) Dual-Radio PoE Access Point

Wireless
Standard: IEEE802.11 ax / ac / n / g / b / a
MIMO: MU-MIMO
Wireless speed: 2.4GHz: 575Mbps, 5GHz: 1200Mbps
Frequency band
2.4 GHz (IEEE 802.11 b / g / n)
Europe (ETSI): 2.412 to 2.462 GHz
5 GHz (IEEE 802.11 a / n / ac)
European (ETSI): 5.15 to 5.35 GHz; 5.470 to 5.725 GHz

RF Design
Antenna type: Dual optimized Antenna
Antenna gain:
2.4GHz: Peak Gain 5dBi
5GHz: Peak Gain 6dBi
Minimum Receive sensitivity: Min. Rx sensitivity up to -101 dBm

WLAN feature
Band Steering: Yes
WDS: Future suppoet
Mesh AP (By License): Future Support
Mesh AP for multiple SSID with VLAN: Future Support
Smart mesh: Future Support
Fast roaming: Pre-authentication, PMK caching and 802.11r
DCS (Auto Channel): Yes
Load balancing: Yes

Security
Wireless Security

• WPA
• WPA-PSK
• WPA-Enterprise (WPA / WPA2 / WPA3)

Access management

• L2-isolation
• MAC filtering
• Rogue AP detection

Networking
IPv6: Yes
VLANs: Yes
WMM: Yes
U-APSD: Yes
DiffServ marking: Yes

Physical Specifications
Dimensions (WxDxH) (mm / in.): 180 x 180 x 39 / 7.09 x 7.09 x 1.54
Weight (g / lb.): 453g / 1
Packing Dimensions (WxDxH) (mm / in.): 229 x 216 x 64 / 9.02 x 8.5 x 2.52
Weight (g / lb.): 770g / 1.7

Physical Interfaces
Ethernet port: 1 x 10/100 / 1000M LAN
Power: PoE (802.3) at: power draw 17 W
DC input: 12 VDC 1.5A
