Интерактивен дисплей ViewSonic IFP8653, 86" (218.44 cm) 4K/UHD TFT LED сензорен дисплей, DisplayPort, HDMI, VGA, USB, USB-C, RS232, SPDIF, LAN

ViewSonic IFP8653

ViewBoard® 86" 4K Interactive Display

• NFC and SSO sign-in for swift access to the intuitive launcher and personal settings
• Quick-start annotation, sketching, and four-color switching with the stylus
• Octa-core CPU with 8GB RAM and 8GB virtual memory for smooth multitasking
• Four USB-C ports ensure seamless connectivity, supporting up to 100W charging
• Android 14 with integrated ViewSonic Education Software

Write Away Effortlessly

Write smoothly, sketch with precision, and annotate with ease directly on the ViewBoard from the moment you pick up the stylus. The IFP53 Series offers a quick-start writing experience that feels as natural and immediate as putting pen to paper. Simply grab your stylus and let your thoughts flow.

Power Through Your Day

Boasting a high-performance octa-core CPU and 8GB of local RAM enhanced by an additional 8GB of virtual memory, the IFP53 Series excels in multitasking. Beyond delivering seamless operation across demanding applications, the IFP53 Series comes equipped with the Android 14, keeping you ahead of the curve with the latest advancements in efficiency, features, and security.

Hear Every Nuance

Boasting an integrated 8-microphone array and precision speakers, the IFP53 Series is designed to capture and deliver every word with remarkable clarity. With advanced noise-canceling technology, it ensures that your voice resonates just as clearly during remote collaboration as it does when you're in the same room.

SPECIFICATIONS:


• Display

  Panel Size: 86"
  Panel Type: TFT LCD Module with DLED Backlight
  Display Area (mm): 1895.04 (H) x 1065.96 (V) (86.5" diagonal)
  Aspect Ratio: 16:9
  Resolution: UHD 3840x2160(Pixels)
  Colors: 1.07B colors
  Brightness: 450 nits (typ)
  Contrast Ratio: 1200:1(Typ.)
  5000:1(Min. with DCR enabled)
  Response Time: 8 ms
  Viewing Angles: H = 178, V = 178 typ.
  Backlight Life: 50,000 hrs (typ).
  Surface Treatment: Hardness: 7H. Anti-glare coating
  Orientation: Landscape


• Platform

  Processor: Octa-Core CPU (A73*4 + A53*4)
  RAM: 8GB (Physical RAM) + 8GB (Virtual Ram) *
  Storage: 128GB


• Touch

  Type/ Tech: UFT (Ultra Fine Touch) Technology
  Touch Resolution: 32767 x 32767
  Touch Point: Windows: 40 points touch, Android: 20 points touch


• INPUT

  HDMI: x4 ( Frontx1:HDMI2.1 with CEC ; Rearx3: (HDMI2.1 with CEC)x2 & (HDMI2.1 with CEC, ARC)x1
  RGB / VGA: x1
  DisplayPort: x1
  Audio: x1 (PC audio in)
  RS232: x1
  OPS: module slot x 1


• OUTPUT

  HDMI: x1
  Audio: x1 (Earphone out)
  SPDIF: x1


• LAN

  RJ45: x2


• USB

  Type A: USB3.0x4 (Frontx2; Rearx2)
  USB2.0x1 (Rear)
  Type B: USB3.0x3 (Frontx1; Rearx2)
  Type C: Input:x3 (Frontx1 with USB3.0, DP1.2, Ethernet 100M, PD 100W; Rearx1 with USB3.0, DP1.2, Ethernet 100M, PD 65W; Rearx1 with USB3.0, PD 15W)
  Output:x1, DP


• SPEAKERS

  16W x 2 front soundbar + 20W x 1 subwoofer


• MICROPHONE

  built-in 8-array microphone


• Top Camera Plate

  Yes


• Embedded OS

  Android 14


• Bundle Software

  Basic Annotation Software: myViewBoard for Android
  Pro Annotation Software: myViewBoard for Windows (embedded in VPC)
  Wireless Presentation: Display, vCast
  Device Management: Manager
  ViewSonic Launcher: Yes


• Special Features

  All-in-one USB port: USB 3.0 “SmartPort USB” to all channels.
  Simple LAN sharing between IFP and slot-in device: 10/100/1000M (USB Type-C 10/100, Android & PC 10/100/1000)
  Light Sensor: Yes
  NFC Reader: Yes
  Pen Sensor: Yes


• Power

  Voltage: 100-240VAC +/- 10% Wide Range
  Consumption: On:131.53W / Off: <0.5W


• ERGONOMICS

  Wall Mount (VESA® ): 800 x 600


• OPERATING CONDITIONS

  Temperature (º C): 0°C to 40°C
  Humidity: 20% ~ 80% RH non-condensing


• DIMENSIONS (W x H x D)

  Physical (inch / mm): 76.87 x 47.13 x 4.66 in / 1952.4 x 1197.2 x 118.4 mm
  Packaging (inch / mm): 85.04 x 51.17 x 8.86 in / 2160 x 1310 x 225 mm


• WEIGHT

  Net (lb / kg): 139.66 lb / 63.35 kg
  Gross (lb / kg): 179.01 lb / 81.2 kg
