IP камера UniVIEW IPC2122SR3-PF40-B, насочена "bullet" камера, 2Mpix(1920x1080@30fps), 4mm обектив, 265/H.264/MJPEG, IR осветеност (до 30m), външна IP66, PoE

UniVIEW IPC2122SR3-PF40-B

Features:

Optics
1. Day/night functionality
2. Smart IR , up to 30 m (98 ft) IR distance
3. Optical glass window with higher light transmittance
4. IR anti-reflection window to increase the infrared transmittance
5. 3D DNR (Digital Noise Reduction)

Compression
1. H.265, H.264, MJPEG
2. Embedded smart algorithm
3. Triple streams
4. 9:16 corridor format

Network
1. ONVIF Conformance

Structure
1. Wide temperature range: -35°C to 60°C (-31°F to 140°F)
2. Wide voltage range of ±25%
3. IP66

Specifications:
Camera
Sensor 1/2.7″, 2.0 megapixel, progressive scan, CMOS
Lens [email protected]
Angle of View(H) 80.8°
Shutter Auto/Manual, 1/6~1/8000 s
Min. Illumination
Colour: 0.02 Lux (F1.8, AGC ON)
0 Lux with IR on
IR Range Up to 30m (98 ft) IR range
Day/Night IR-cut filter with auto switch (ICR)
S/N >52dB
WDR Digital
Noise Reduction 2D/3D

Video
Max. Resolution 1920×1080
Video Compression H.265, H.264, MJPEG
Frame Rate 1080P (1920*1080): Max. 30 fps; 720P (1280*720): Max. 30 fps; D1 (720*576): Max. 25 fps
Video Streaming Triple
9:16 Corridor Mode Supported
ROI Supported
OSD Up to 8 OSDs
Motion Detection Up to 2 areas
Privacy Mask Up to 8 areas

Smart
Behavior Detection Intrusion, crossing line, motion detection
Exception Detection Audio detection
Intelligent Identification Face detection
Statistical Analysis People counting

Network
Protocols
L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP,
802.1x
Compatible Integration ONVIF, API

Interface
Network 1 RJ45 10M/100M Base-TX Ethernet

General
Power
12 V DC, or PoE (IEEE802.3 af)
Power consumption: Max 6.4 W
Dimensions (L × W × H) 157.3 × 62.4 ×63 mm (6.2” × 2.5” × 2.5”)
Weight 0.45 kg (0.99 lb)
Working Environment -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing)
Ingress Protection IP66
