Ubiquiti Rocket AC Lite
Enclosure Outdoor UV stabilized plastic
Processor Atheros MIPS 74Kc, 720 MHz
Memory 128 MB DDR2 SDRAM, 16 MBNOR Flash
Networking Interface 1 x 10/100/1000 Mbps
RF Connections 2 x RP-SMA waterproof
LEDs 4 x signal strength
Power
Ethernet
Max Power Consumption 8.5 W
Power Supply 24 V, 0.5 A Gigabit PoE adapter
Power Method Passive PoE (Pairs 4, 5+, 7, 8 return)
ESD/EMP Protection ± 24 KV air / contact
Operating Temperature -40 to 176°F / -40 to 80°C
Operating Humidity 5 to 95% non-condensing
Shock and Vibration ETSI300-019-1.4
Software Specifications
Modes Access Point Station
Services Web Server
SNMP
SSH Server
Telnet
Ping Watchdog
DHCP
NAT
Bridging
Routing
Utilities Antenna Alignment Tool
Discovery Utility
Site Survey
Ping
Traceroute
Speed Test
Distance Adjustment Dynamic Ack and Ackless Mode
Power Adjustment Range Software Adjustable UI or CLI
Security WPA2 AES Only
QoS Supports Packet Level Classification WMM and User Customer Level: High/medium/low
Statistical Reporting Up Time
Packet Errors
Data Rates
Wireless Distance
Ethernet Link Rate
Channel Sizes PtP Mode
10/20/30/40/50/60/80 MHz
PtMP Mode
10/20/30/40 MHz
Other Remote Reset Support
Software Enabled/Disabled
VLAN Support
256QAM
Ubiquiti Specifications 30/50/60 MHz Channels
airMAX ac Mode
Traffic Shaping with Burst Support
Discovery Protocol
Frequency Band Offset
Ackless Mode
Compliance and Approvals
Wireless Approvals FCC, IC, CE
RoHS Compliance Yes
Frequency
Operating Frequency Worldwide: 5150 - 5875 MHz
USA: 5725 - 5850 MHz
Output Power 27 dBm
TX Power Specifications Modulation
airMAX ac
Data Rate Avg. TX Tolerance
1x BPSK (1/2) 27 dBm ± 2 dB
2x QPSK (1/2) 27 dBm ± 2 dB
2x QPSK (3/4) 27 dBm ± 2 dB
4x 16QAM (1/2) 27 dBm ± 2 dB
4x 16QAM (3/4) 27 dBm ± 2 dB
6x 64QAM (2/3) 27 dBm ± 2 dB
6x 64QAM (3/4) 26 dBm ± 2 dB
6x 64QAM (5/6) 25 dBm ± 2 dB
8x 256QAM (3/4) 23 dBm ± 2 dB
8x 256QAM (5/6) 22 dBm ± 2 dB
RX Power Specifications Modulation
airMAX ac
Data Rate Avg. TX Tolerance
1x BPSK (1/2) -96 dBm ± 2 dB
2x QPSK (1/2) -95 dBm ± 2 dB
2x QPSK (3/4) -92 dBm ± 2 dB
4x 16QAM (1/2) -90 dBm ± 2 dB
4x 16QAM (3/4) -86 dBm ± 2 dB
6x 64QAM (2/3) -83 dBm ± 2 dB
6x 64QAM (3/4) -77 dBm ± 2 dB
6x 64QAM (5/6) -74 dBm ± 2 dB
8x 256QAM (3/4) -69 dBm ± 2 dB
8x 256QAM (5/6) -65 dBm ± 2 dB
Dimensions & Weight
Dimensions 6.38 x 3.31 x 1.46" / 162 x 84 x 37 mm
Weight 8.81 oz / 250 g
Виж още Аксеспойнт/Репитер Безжични Ubiquiti
Виж всички Аксеспойнт/Репитер Безжични в категорията
Enclosure Outdoor UV stabilized plastic
Processor Atheros MIPS 74Kc, 720 MHz
Memory 128 MB DDR2 SDRAM, 16 MBNOR Flash
Networking Interface 1 x 10/100/1000 Mbps
RF Connections 2 x RP-SMA waterproof
LEDs 4 x signal strength
Power
Ethernet
Max Power Consumption 8.5 W
Power Supply 24 V, 0.5 A Gigabit PoE adapter
Power Method Passive PoE (Pairs 4, 5+, 7, 8 return)
ESD/EMP Protection ± 24 KV air / contact
Operating Temperature -40 to 176°F / -40 to 80°C
Operating Humidity 5 to 95% non-condensing
Shock and Vibration ETSI300-019-1.4
Software Specifications
Modes Access Point Station
Services Web Server
SNMP
SSH Server
Telnet
Ping Watchdog
DHCP
NAT
Bridging
Routing
Utilities Antenna Alignment Tool
Discovery Utility
Site Survey
Ping
Traceroute
Speed Test
Distance Adjustment Dynamic Ack and Ackless Mode
Power Adjustment Range Software Adjustable UI or CLI
Security WPA2 AES Only
QoS Supports Packet Level Classification WMM and User Customer Level: High/medium/low
Statistical Reporting Up Time
Packet Errors
Data Rates
Wireless Distance
Ethernet Link Rate
Channel Sizes PtP Mode
10/20/30/40/50/60/80 MHz
PtMP Mode
10/20/30/40 MHz
Other Remote Reset Support
Software Enabled/Disabled
VLAN Support
256QAM
Ubiquiti Specifications 30/50/60 MHz Channels
airMAX ac Mode
Traffic Shaping with Burst Support
Discovery Protocol
Frequency Band Offset
Ackless Mode
Compliance and Approvals
Wireless Approvals FCC, IC, CE
RoHS Compliance Yes
Frequency
Operating Frequency Worldwide: 5150 - 5875 MHz
USA: 5725 - 5850 MHz
Output Power 27 dBm
TX Power Specifications Modulation
airMAX ac
Data Rate Avg. TX Tolerance
1x BPSK (1/2) 27 dBm ± 2 dB
2x QPSK (1/2) 27 dBm ± 2 dB
2x QPSK (3/4) 27 dBm ± 2 dB
4x 16QAM (1/2) 27 dBm ± 2 dB
4x 16QAM (3/4) 27 dBm ± 2 dB
6x 64QAM (2/3) 27 dBm ± 2 dB
6x 64QAM (3/4) 26 dBm ± 2 dB
6x 64QAM (5/6) 25 dBm ± 2 dB
8x 256QAM (3/4) 23 dBm ± 2 dB
8x 256QAM (5/6) 22 dBm ± 2 dB
RX Power Specifications Modulation
airMAX ac
Data Rate Avg. TX Tolerance
1x BPSK (1/2) -96 dBm ± 2 dB
2x QPSK (1/2) -95 dBm ± 2 dB
2x QPSK (3/4) -92 dBm ± 2 dB
4x 16QAM (1/2) -90 dBm ± 2 dB
4x 16QAM (3/4) -86 dBm ± 2 dB
6x 64QAM (2/3) -83 dBm ± 2 dB
6x 64QAM (3/4) -77 dBm ± 2 dB
6x 64QAM (5/6) -74 dBm ± 2 dB
8x 256QAM (3/4) -69 dBm ± 2 dB
8x 256QAM (5/6) -65 dBm ± 2 dB
Dimensions & Weight
Dimensions 6.38 x 3.31 x 1.46" / 162 x 84 x 37 mm
Weight 8.81 oz / 250 g
Виж още Аксеспойнт/Репитер Безжични Ubiquiti
Виж всички Аксеспойнт/Репитер Безжични в категорията
Технически характеристики
Тип: | Аксес пойнт |
---|---|
Монтаж: | За външен монтаж |
Безжична скорост: | 500 Mbps |
Wi-Fi Стандарт: | Wi-Fi 5 (802.11ac) |
Честота: | 5 GHz |
Антени: | 2 Изхода |
dBi на антена/и: | Не е указано |
PoE: | In |
Интерфейс: | 1x 1000 |
Други: | Няма |
