Суич TP-Link Festa FS308GP, 1000 Mbps, 4 порта, 8x 10/100/1000Mbps (4x PoE+)

Festa FS308GP

8-Port Gigabit Smart Switch with 4-Port PoE+

• 8× Gigabit ports (4× 802.3at/af-compliant PoE+ ports)
• 62W total PoE budget with up to 30W PoE output per port*
• Complete business-class Festa Ecosystem with consumer-inspired simplicity
• Free cloud centralized management via the Festa app or the web†
• Easy setup and management
• Zero-Touch Provisioning (ZTP) and Self-Organizing Networking (SON)
• Static Routing, VLAN, ACL, and IGMP Snooping
• Fanless design for silent operation
• Elegant metal casing and desktop/wall mounting design







Festa 一 A Networking Solution Built For Small Business, No IT Required

Festa offers business-class features with consumer-inspired simplicity. Our free cloud-based centralized management is accessible via the Festa app or web, providing essential features for small businesses without the complexity required by larger-scale operations.





HARDWARE FEATURES
Interface	• 8× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3at PoE+ and 802.3af PoE) • Auto-Negotiation/Auto MDI/MDIX
Fan Quantity	Fanless
Physical Security Lock	√
Power Supply	External Power Adapter (Output: 53.5 VDC/ 1.31 A)
Power Consumption	• Max Power Consumption: 77.3 W (110 V/60 Hz) (with 62 W PD connected) • Standby Power Consumption: 2.8 W (110V/60 Hz)
PoE Ports (RJ45)	• Standard: 802.3af/at compliant • PoE Ports: 4 Ports • Power Supply: 62 W*
Dimensions ( W x D x H )	8.2×4.9×1.0 in (209×126×26 mm)
Mounting	Desktop / Wall-Mounting

PERFORMANCE
Switching Capacity	16 Gbps
Packet Forwarding Rate	11.90 Mpps
MAC Address Table	8k
Packet Buffer Memory	4.1 Mbit
Jumbo Frame	9 KB

SOFTWARE FEATURES
L2 and L2+ Features	• 16 IP Interfaces: Support IPv4/IPv6 Interface • Static Routing: 32 IPv4/IPv6 Static Routes • DHCP Server • DHCP Relay • DHCP L2 Relay • Spanning Tree • Loopback Detection • Flow Control • 802.1ab LLDP/ LLDP-MED
Advanced Features	• IGMP Snooping • Rate Limit • Storm Control • Port Isolation
IPv6 Support	√
VLAN	√
Access Control List	• Time-Range - Time Slice - Week Time-Range - Absolute Time-Range • Combined ACL - Source MAC(Subnet Mask) - Destination MAC(Subnet Mask) - VLAN ID - EtherType - Source IP(Subnet Mask) - Destination IP(Subnet Mask) - IP Protocol - TCP/UDP Source Port - TCP/UDP Destination Port • IPv6 ACL • Rule Operation - Permit/Deny • Binding - Port Binding - VLAN Binding
Link Aggregation	√

MANAGEMENT
Centralized Management	• Festa App • Festa Web Portal
Cloud Access	Free Cloud Access
Management Features	• Zero-Touch Provisioning (ZTP) • Self-Organizing Network (SON) • Auto Topology • Multi-site Management • Remote Maintenance • Batch Firmware Upgrading • Batch Configuration • Integrated Troubleshooting Tools • Monitor Network Status • Access Condition Logs and Alerts

OTHERS
Certification	CE, FCC, RoHS
System Requirements	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux.
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
