Суич Tenda SG105M, 2500Mbps, 5 порта, 5x 10/100/1000 Mbps RJ-45

TP-Link TL-SG105M



All Gigabit Ports, High-speed Network





Small And Exquisite, Save More Space

82*52*22mm super mini body, smaller than a bank card. It also supports a wall mount and can be placed anywhere.





Specifications:



Hardware

Network standards

IEEE802.3
IEEE802.3u
IEEE802.3x
IEEE802.3ab



LED Indicator

One Link/Act LED indicator for each Gigabit port
One Power LED indicator for each device



Interfaces

5*10/100/1000Base-T Ethernet ports



Transmission media

Ethernet: CAT3 UTP or better
Fast Ethernet: CAT5 UTP or better
Gigabit Ethernet: CAT5e UTP or better



Fan quantity

N/A



Dimension

82mm*52mm*22mm(L*W*H)



Material

Plastic



Forwarding mode

Store-and-forward



Packet forwarding rate

7.44Mpps



Buffer

1Mb



MAC address table

2K



Jombo frame

15K



Power

Input: 100-240V AC 50/60Hz
Output: 5.0V 0.6A ( External Power Adapter )



Power consumption

Max:<1.7W



Mounting

" Desktop mounting: support
Wall mounting: support
Rack mounting:non-support"



Environment

Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%) RH, non-condensing
Storage humidity: (5% - 90%) RH, non-condensing





Software

MAC address learning

Auto-learning and Auto-Updating



Funtions

plug-and-play
