Захранване Sharkoon SHP Bronze SHPBRONZE700, 700W, Active PFC, 80 Plus Bronze, 120mm вентилатор

Sharkoon SHP Bronze

 The Sharkoon SHP Bronze is a durable ATX power supply with “80 PLUS Bronze” certification. The power supply can be simply installed into common ATX cases and remains conveniently inconspicuous with its black cables and black housing. Ample cooling is ensured through the quiet operation of the 120 mm fan.

Energy Efficient Running. This power supply is certified “80 PLUS Bronze” achieving at least 85 % energy efficiency at 50 % load, as well as at least 82 % efficiency at 20 % and 100 % loads.

Low-Profile Simplicity. The power supply can be installed and connected easily and quickly. Its metallic housing, the fan grille as well as the connectors and the cable sheathing have all been kept completely in black. This allows the power supply to be inconspicuously integrated into the PC casing.

Specifications:

General

Form Factor:
    ATX 2.3
Continuous Power:
    700 W
ErP Compliant:
    Yes
Active PFC:
    Yes
Technology:
    AC/DC
MTBF:
    Min. 100,000 Hours
Operating Temperature:
    0 °C - 40 °C
Standby Power Consumption:
    0.3 W
Weight incl. Fixed Cables:
    1.6 kg
Dimensions (L x W x H):
    140 x 150 x 86 mm
Housing Color:
    Black

Input
Voltage:
    100 - 240 VAC
Frequency:
    47 - 63 Hz
Input Current (110/230 V):
    12 A / 6 A

Output
12 V Rail(s):
    1
Load 3.3 V:
    20 A
Load 5 V:
    20 A
Max. Combined Power 3.3 V + 5 V:
    130 W
Load 12 V1:
    53 A
Max. Combined Power 12 V:
    636 W
Load 5 VSB:
    2.5 A
Load -12 V:
    0.3 A

Cable and Connectors
Cable Configuration:
    Fixed
Flat Cables:
    Yes
Maximum Cable Length:
    120 cm
Length of Mainboard Cable:
    55 cm
Length of CPU Cable:
    60 cm + 15 cm
Length of PCIe Cable:
    55 cm + 15 cm
Cable Length to First Peripheral:
    55 cm
20+4-Pin Mainboard Connector:
    1
4+4-Pin CPU Connector:
    1
8-Pin CPU Connector:
    1
6+2-Pin PCIe Connector:
    4
SATA Connector:
    6
IDE Connector:
    3

Fan
Fan Size:
    120 mm
Bearing Type:
    Sleeve Bearing

Protections
OVP (Over Voltage Protection):
    Yes
UVP (Under Voltage Protection):
    Yes
SCP (Short Circuit Protection):
    Yes
OPP (Over Power Protection):
    Yes

Safety Certifications
CE:
    Yes
FCC:
    Yes
