Захранване Seasonic CORE GX ATX 3 (2024), 850W, Active PFC, 80 Plus Gold, 120mm вентилатор

Seasonic CORE GX ATX 3 (2024)
1C285GFRT3A10X

Total power: 850W
80PLUS: Gold
Cybenetics Efficiency Level: TBA
Cybenetics Noise Level: TBA
Form Factor: ATX/EPS
Dimensions: 140 × 150 × 86 mm
Fan Information
Fan Size: 120 mm
Fan Control: Smart and Silent Fan Control
Fan Bearing: Hydro Dynamic Bearing
Life Expectancy: 25,000 hours at 40 °C, 15 % — 65 % RH

Cable Information
Modularity: Fully Modular
Cable type: Individual Black Cables with Braided Pattern

Electrical Features
Operating Temperature: 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C linearly)
MTBF @ 25 °C, excl. fan: 100,000 hours
AC Input: Full Range
Protection: OCP, OPP, OTP, OVP, SCP, UVP
Safety and Environmental
Safety and EMC: BSMI, C-tick, CB, CCC, CE, cTUVus, EAC, FCC, TUV, UKCA
Environmental Compliance: Energy Star, ErP Lot 6, REACH, RoHS, WEEE

Power Output
AC Input
100 V - 240 V
11 - 5.5 A
50 Hz - 60 Hz

Cables
MB (24/20 pins): 610 mm, 1 connector, 1 cable
CPU (8/4 pins): 750 mm, 1 connector, 2 cables
12V-2x6 (12+4 Pins to 12+4 Pins): 700 mm, 1 connector, 1 cable
PCIe (8/6 pins): 750 mm, 1 connector, 1 cable
PCIe (8/6 pins): 700 mm, 2 connectors, 1 cable
SATA: 750 mm, 3 connectors, 2 cables
Molex: 690 mm, 3 connectors, 1 cable
