Видео карта AMD Radeon RX 5600 XT, 6GB, SAPPHIRE PULSE (11296-05-20G), PCI-E 4.0, GDDR6, 192-bit, DP, HDMI

PULSE RX 5600 XT BE 6G GDDR6

• GPU: Boost Clock: Up to 1620 MHz
• Memory:   6GB/192 bit GDDR6. 14 Gbps Effective
• Stream Processors:2304
• 4K@60Hz
• Dual-X Cooling Technology
• *No Quick Connect Fan / Dual BIOS





SAPPHIRE PULSE RX 5600 XT BE

The SAPPHIRE PULSE RX 5600 XT BE offers incredible performance at the optimal budget for every gamer. With lightning fast GDDR6 memory and redefined display and media engines, the PULSE RX 5600 XT BE is the ideal graphics card for 1080p gamers. It is powered by AMD’s extreme RDNA architecture, alongside our innovative Dual-X Cooling Technology which keeps the GPU, Memory and VRM components icy cool at low noise levels. The all-aluminum backplate preserves the rigidity of the GPU and guarantees nothing bends, dust stays out and adds another level of passive cooling to dissipate heat. Efficient cooling solutions alongside the SAPPHIRE exclusive TriXX Boost feature will give you a boost in performance whilst keeping your GPU running smooth and stable. Take your gaming to the next level with the SAPPHIRE PULSE RX 5600 XT BE as the beating heart of your PC!













Specifications:



GPU

Engine Clock

• Boost Clock: Up to 1620 MHz
• Game Clock: Up to 1560 MHz

Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors

Memory Size/Bus

Memory Clock

Displays

Resolution

Interface

PCI-Express 4.0

Output

• 2x HDMI
• 2x DisplayPort

BIOS Support

• UEFI

API

• Vulkan®
• OpenGL® 4.6
• OpenCL 2.0
• DirectX® 12
• Shader Model 6.4

Game Index

Extreme 1080P, 1440P Entry

Sapphire Features

• Power Design
• Free Flow
• TriXX Supported
• TriXX Boost
• Intelligent Fan Control
• Precision Fan Control
• Robust VRM Cooling
• Dual-X Cooling Technology
• Tough Metal Backplate
• PCB Layers
• Two-Ball Bearing
• Fuse Protection

AMD Features

• RDNA Architecture
• 2nd Gen 7nm GPU
• GDDR6 Memory
• Power Efficiency
• PCI Express 4.0 Support
• Video Streaming up to 8K
• Display Port 1.4 (HBR3) / DSC
• Radeon™ Software
• Radeon™ Boost
• Radeon™ Image Sharpening
• Radeon™ Anti-Lag
• AMD FidelityFx
• Async Compute
• Radeon™ Rays Audio + True Audio Next
• Radeon™ FreeSync™ 2 HDR

Cooling

• Dual-X Cooling
• Dual Fan
• Two-Ball Bearing

Form Factor

Power Consumption

• 150W

OS

Linux®, Windows®  10, Windows®  7 64bit operating system required

System Requirement

• Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply).
• 1 x 8-pin Power Connector.
• PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
• Minimum 4GB of system memory. 8GB recommended.
