Мрежови диск (NAS) QNAP TS-364-4G, четириядрен Jasper Lake Intel Celeron N5105 2.0/2.9 GHz, без твърд диск (3x SATA 6Gb/s), 4GB DDR4, 1x (2.5G/1G/100M)

QNAP TS-364-4G

CPU
Intel® Celeron® N5105/N5095 4-core/4-thread processor, burst up to 2.9 GHz

CPU Architecture
64-bit x86

Graphic Processors
Intel® UHD Graphics

Floating Point Unit

Encryption Engine
(AES-NI)

Hardware-accelerated Transcoding

System Memory
4 GB SODIMM DDR4 (1 x 4 GB)

Maximum Memory
16 GB (2 x 8 GB)

Memory Slot
2 x SO-DIMM DDR4

When installing two memory modules, please ensure that they are the same size and ideally use the same type of RAM for both memory slots.
Flash Memory
5GB (Dual boot OS protection)

Drive Bay
3 x 3.5-inch SATA 6Gb/s, 3Gb/s

Drive Compatibility
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

An optional 2.5" drive tray base (TRAY-25-NK-BLK03) is needed to install a 2.5" SSD/HDD

Hot-swappable

M.2 Slot
2 x M.2 2280 PCIe Gen 3 x2 slots
SSD Cache Acceleration Support

2.5 Gigabit Ethernet Port (2.5G/1G/100M)
1(2.5G/1G/100M)

Wake on LAN (WOL)
Jumbo Frame
USB 3.2 Gen 1 port
1

USB 3.2 Gen 2 (10Gbps) Port
2 x Type-A

HDMI Output
1, HDMI 1.4b (up to 4096 x 2160 @ 30Hz)

Form Factor
Tower

LED Indicators System Status, LAN, USB, HDD1~3, M.2 SSD1~2
Buttons
Power, Reset, USB Copy

Dimensions (HxWxD)
142 × 150 × 260 mm

Weight (Net)
1.64 kg

Operating temperature
0 - 40 °C (32°F - 104°F)

Storage Temperature
-20 - 70°C (-4°F - 158°F)

Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit
65W adapter, 100 - 240V

Power Consumption: Operating Mode, Typical
32.8 W

Tested with drives fully populated.

Fan
1 x 92mm, 12VDC

System Warning Buzzer
Kensington Security Slot

Max. Number of Concurrent Connections (CIFS) - with Max. Memory
1500
