Процесор AMD Ryzen 9 7900, дванадесетядрен (3.70/5.40GHz, 64MB Cache, 0.40-2.20GHz GPU, AM5) BOX, с охлаждане AMD Wraith Prism

AMD Ryzen 9 7900
100-100000590BOX

General Specifications

Platform
Desktop

Market Segment
Enthusiast Desktop

Product Family
AMD Ryzen™ Processors

Product Line
AMD Ryzen™ 9 Processors

Consumer Use
Yes

Regional Availability
Global, China, NA, EMEA, APJ, LATAM

Former Codename
"Raphael AM5"

Architecture
"Zen 4"

# of CPU Cores
12

Multithreading (SMT)
Yes

# of Threads
24

Max. Boost Clock
Up to 5.4GHz

Base Clock
3.7GHz

L1 Cache
768KB

L2 Cache
12MB

L3 Cache
64MB

Default TDP
65W

Processor Technology for CPU Cores
TSMC 5nm FinFET

Processor Technology for I/O Die
TSMC 6nm FinFET

CPU Compute Die (CCD) Size
71mm²

I/O Die (IOD) Size
122mm²

Package Die Count
1

Unlocked for Overclocking
Yes

AMD EXPO™ Memory Overclocking Technology
Yes

Precision Boost Overdrive
Yes

Curve Optimizer Voltage Offsets
Yes

AMD Ryzen™ Master Support
Yes

CPU Socket
AM5

Supporting Chipsets
X670E
X670
B650E
B650

CPU Boost Technology
Precision Boost 2

Instruction Set
x86-64

Supported Extensions
AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64

Thermal Solution (PIB)
AMD Wraith Prism

Max. Operating Temperature (Tjmax)
95°C

*OS Support
Windows 11 - 64-Bit Edition
Windows 10 - 64-Bit Edition
RHEL x86 64-Bit
Ubuntu x86 64-Bit
*Operating System (OS) support will vary by manufacturer.

Connectivity

USB Type-C® Support
Yes

Native USB 3.2 Gen 2 (10Gbps) Ports
4

Native USB 2.0 (480Mbps) Ports
1

Native PCIe® Lanes (Total/Usable)
28/24

Additional Usable PCIe Lanes from Motherboard
AMD X670E
12x Gen4

AMD X670
12x Gen4

AMD B650E
8x Gen4

AMD B650
8x Gen4

NVMe Support
Boot, RAID0, RAID1, RAID10

System Memory Type
DDR5

Memory Channels
2

Max. Memory
128GB

System Memory Subtype
UDIMM

Max Memory Speed
2x1R
DDR5-5200

2x2R
DDR5-5200

4x1R
DDR5-3600

4x2R
DDR5-3600

ECC Support
Yes (Requires mobo support)

Graphics Capabilities


Integrated Graphics
Yes

Graphics Model
AMD Radeon™ Graphics

Graphics Core Count
2

Graphics Frequency
2200 MHz

GPU Base
400 MHz

USB Type-C® DisplayPort™ Alternate Mode
Yes
