ZU500TST

DuraCore

Industry leading lifetime is achieved using Optoma’s DuraCore technology. Implementing advanced laser diode cooling techniques and an innovative dust resistant design.

PureShift

Simplify installation with PureShift, which provides a wide range of projector placement possibilities.

Full 360 projection

Images can be projected over a full 360° range along the projector’s horizontal axis.

Portrait projection

Ideal for digital signage applications you can rotate your projector 90 degrees to project a portrait image.

Vertical and portrait projection

Images can be projected vertically up and down and in portrait orientations.

	IP5X Dust resistant optical engine Independently tested and certified to IEC standard 60529 with an IP5X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry leading durability; paramount for 24/7 maintenance free operation in challenging environments.
	Picture by picture picture-in-picture Signals can be delivered simultaneously via the HDMI and DVI ports, for a PbP or PiP display from two digital sources – perfect for video-conferencing and other collaborative applications.
	HDBaseT™ Uncompromising, uncompressed Full HD video, audio, network and control commands all delivered on a single CAT- type cable capable up to 100 meters/328 feet without signal loss makes installation hassle-free. HDBaseT™ simplifies cabling requirements and reduces installation complexity saving both time and reducing costs.
	PJLink PJLink protocol is incorporated into the projector allowing for easy installation with PJLink compatible control systems.
	Telnet This model is able to receive comands via telenet allowing for easy installation with Telnet compatible control systems.
	MHL Turn your projector into a smart display by connecting your smartphone or tablet with a single cable using MHL; now you can view presentations and documents, stream videos and share photos on the big screen.

Quick resume

This feature allows the projector to be instantly powered on again, if it is accidentally switched off.

Amazing colour

Optoma projectors provide reliable colour performance suitable for any content and environment. From accurate sRGB colours for lifelike images to vibrant punchy presentations. We have a display mode to specific meet your needs. Perfect for a range of graphic and video presentations.

Superior contrast

Add more depth to your image with a high contrast projector. Compared to competing technology, Optoma DLP projectors provide you with brighter whites and ultra-rich blacks, images come alive and text appears crisp and clear - ideal for business and education applications.

Four-corner adjustment

Individually warp each corner of the image to create a perfectly square image. Ideal for image stacking, uneven walls or where projector placement is awkward and needs to be installed at an angle.

Control

Featuring a wide range of options you can control and monitor the projector remotely.

• RS232 Optoma projector’s come with an extensive set of RS232 commands making it simple and easy to manage using any control system.

• AMX Compatibility Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.

• LAN Control Using the compatible RoomView® software you can power on/off, monitor, manage and control up to 250 projectors at the same time from any computer. • Schedule the projectors to power on/off. • Control and alter the projector settings using the simple web browser. • Emergency text broadcast capabilities for urgent or important announcements. • Automatically receive email updates for lamp maintenance.

Full 3D

Optoma projectors can display true 3D content from almost any 3D source, including 3D compatible graphics cards, 3D broadcasting and the latest generation 3d media servers.

Integrated speaker

A powerful built-in speaker provides exceptional sound quality and an easy setup without the need for costly external speakers.

USB-Power

Use the USB-Power to power an HDMI dongle

Wired remote

The wired remote connection allows all aspects of the projector to be individually controlled without requiring a line-of-sight to the projector; invaluable when using multiple units during live events.

AV mute

Stay in control of your presentation with AV mute. Direct your audience's attention away from the screen by blanking the image when not needed.

Direct power on

The projector will start up instantly when power is supplied to the unit. This eliminates the need to manually turn on the projector via the remote control or the keypad, ideal for use in rooms with a “master” power switch.

Direct power off

Power off your projector immediately or directly at the mains. This means you don’t have to wait for the projector to cool down before turning it off.

24/7 operation

Optoma projectors have been designed to operate 24 hours a day in standard orientation. Perfect for applications where prolonged periods of use is required. Subject to 24 hour terms and conditions.

24/7 Operation - standard lamp warranty applies. Projector warranty is based on standard business usage hours. For optimum performance Optoma recommends that your projector is turned off or placed in standby mode for 30 minutes every 24 hours to prolonging the life of your lamp.

Customise your projector

Have your projector in any colour. Chose from any RAL colour. Perfect for bespoke installations. *Contact us for more information"

Specification

Display/Image
Display technology: DLP
Resolution: WUXGA (1920x1200)
Brightness: 5,000 lumens
ANSI brightness: 5,000 lumens
Contrast ratio: 300,000:1
Native aspect ratio: 16:10
Aspect ratio - compatible: 4:3,16:9,16:10
Keystone correction - horizontal: +/-30°
Keystone correction - vertical: +/-30°
Horizontal scan rate: 15.375 ~ 91.146Khz
Vertical scan rate: 24 ~ 85(120 for 3D)Hz
Uniformity: 85%
Screen size: 0.75m ~ 7.76m (29.4" ~ 305.6") (diagonal)

Lamp info
Light source type: Laser
LASER life: 20,000 hours

Optical
Throw ratio: 0.79:1
Projection distance (m): 0.5m - 5.2m
Zoom type: Fixed
Focal length (mm): 17.63 ~ 31.36
Lens shift: Vertical +13%, Horizontal +5%
Native offset: 100%

Connectivity
Connections:
Inputs 1 x VGA (YPbPr/RGB), 1 x HDMI 1.4a 3D support, 1 x Audio 3.5mm, 1 x Microphone, 1 x RS232, 1 x USB-A power 1.5A, 1 x USB-B service, 1 x Wired remote, 1 x RJ45, 1 x HDBaseT, 1 x HDMI 1.4a 3D support + MHL, 1 x 3D sync
Outputs 1 x VGA (YPbPr/RGB), 1 x Audio 3.5mm, 1 x 12V trigger

General
Noise level (typical): 28dB
PC compatibility: FHD, UXGA, SXGA, WXGA, HD, XGA, SVGA, VGA, Mac
2D compatibility: NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4,43MHz SECAM B/D/G/K/K1/L, 4.25/4.4MHz 480i/p, 576i/p, 720p(50/60Hz), 1080i(50/60Hz), 1080p(50/60Hz)
3D compatibility: Side-by-Side:1080i50 / 60, 720p50 / 60 Frame-pack: 1080p24, 720p50 / 60 Over-Under: 1080p24, 720p50 / 60
3D: Full 3D
Security: Security bar,Kensington Lock,Password protected interface
OSD / display languages: 18 languages: Arabic,Danish,Dutch,English,Finnish,French,German,Italian,Japanese,Norwegian,Polish,Portuguese,Russian,Chinese (simplified),Spanish,Chinese (traditional),Turkish
24/7 operation: Yes
360° operation: Yes
Operating conditions: 5°C ~ 40°C, Max. Humidity 90%, Max. Altitude 3000m
Remote control: Wired backlit PRO AV remote
Speaker count: 2
Watts per speaker: 10W
In the box: AC power cord, Remote control, 2x AAA batteries, Basic user manual

Networking
LAN - control: Yes

Power
Power supply: 100 ~ 240V, 50 ~ 60Hz
Power consumption (standby): 0.5W
Power consumption (min): 320W
Power consumption (max): 480W

Weight and dimensions
Net weight: 11kg
Dimensions (W x D x H) mm: 405 x 387 x 159

Виж още Проектори Optoma
Виж всички Проектори в категорията

Документация

Data Sheet

Технически характеристики

Тип:	DLP
3D:	3D
Разделителна способност (native):	1920 x 1200
Разделителна способност (max):	1920 x 1200
Яркост:	5000 lm
Контраст:	300000
Мрежови възможности:	RJ-45 & HDBaseT
Говорители:	Да
4K:	Не
Разстояние на проектиране:	0.5m - 5.2m
Short Throw:	Да
