Памет 64GB (2x32GB) DDR5 5200MT/s, Kingston FURY Beast, KF552C36BBEAK2-64, 1.25V

Kingston FURY Beast

DESCRIPTION

Kingston FURY KF552C36BBEAK2-64 is a kit of two 4G x 64-bit
(32GB) DDR5-5200 CL36 SDRAM (Synchronous DRAM) 2Rx8,
memory module, based on sixteen 2G x 8-bit FBGA components per
module. Each module kit supports AMD® EXPO v1.0 and
Intel® Extreme Memory Profiles (Intel® XMP) 3.0. Total kit
capacity is 64GB. Each module has been tested to run at
DDR5-5200 at a low latency timing of 36-38-38 at 1.25V. The
SPDs are programmed to JEDEC standard latency
DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM
uses gold contact fingers. The JEDEC standard electrical
and mechanical specifications are as follows:

SPECIFICATIONS

FEATURES

• Power Supply: VDD = 1.1V Typical
• VDDQ = 1.1V Typical
• VPP = 1.8V Typical
• VDDSPD = 1.8V to 2.0V
• On-Die ECC
• Height 1.66” (42.23mm), w/heatsink

FACTORY TIMING PARAMETERS

• Default (JEDEC): DDR5-4800 CL40-39-39 @1.1V
• EXPO Profile #0: DDR5-5200 CL36-38-38 @1.25V
• EXPO Profile #1: DDR5-4800 CL38-38-38 @1.1V
• XMP Profile #1: DDR5-5200 CL36-38-38 @1.25V
• XMP Profile #2: DDR5-4800 CL38-38-38 @1.1V
