Монитор IIYAMA T2438MSC-B1, 23.8" (60.45cm) IPS панел, Full HD, 5ms, 1000:1, 600cd/m2, DisplayPort, HDMI, USB

IIYAMA T2438MSC-B1

23.8” 10pt Optical Bonded PCAP touchscreen monitor with IPS panel technology, edge-to-edge glass design, anti-fingerprint coating and metal housing

The Full HD (1920x1080) monitor ProLite T2438MSC-B1 with IPS panel technology offers exceptional colors and wide viewing angles. The Optical Bonded Projective Capacitive (PCAP) 10-point touch technology ensures a seamless and accurate touch response and a lower light reflection, in addition, the display is protected against humidity and potential moisture development. A robust metal housing and a scratch-resistant 7H edge-to-edge glass with anti-fingerprint coating make the monitor particularly suitable for integration in demanding environments. The monitor meets also a IPX1 protection rating, making it waterproof for a period of time against dripping water.

The flexible stand can be positioned at several angles creating a comfortable and ergonomic user experience and the integrated cable management system hides all the cables and electrical wires giving a neat and cable-free workspace. The ProLite T2438MSC-B1 can be used in landscape, portrait and face-up orientation. A perfect solution for interactive signage, instore retail, POS and interactive presentations.



Optical bonded PCAP

The optical bonded projective capacitive (PCAP) touch technology reduces the air gap between the touch layer and the display making the touch response more accurate. It improves also the visual quality by reducing reflections and glare. In addition the display is protected against dust and potential moisture development.





IPS Technology

IPS displays are best known for wide viewing angles and natural, highly accurate colours. They are especially suited for colour-critical applications.





Scratch resistance

Scratch resistance is essential for touch solutions used in public places and schools. This is achieved thanks to a glass overlay covering the screen. It guarantees high durability of the touch function and even more importantly the touch function remains unaffected even if the glass is scratched.





Speakers

This LED monitor is equipped with two high quality stereo speakers.





Specifications:



DISPLAY CHARACTERISTICS
Design     Edge to edge glass
Diagonal     23.8", 60.5cm
Panel     IPS
Native resolution     1920 x 1080 (2.1 megapixel Full HD)
Aspect ratio     16:9
Panel brightness     600 cd/m²
Brightness     525 cd/m² with touch
Light transmittance     87%
Static contrast     1000:1
Response time (GTG)     5ms
Viewing zone     horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°
Colour support     16.7mln
Horizontal Sync     30 - 83kHz
Viewable area W x H     527 x 296.5mm, 20.7 x 11.7"
Bezel width (sides, top, bottom)     17.25mm, 20.3mm, 20.3mm
Pixel pitch     0.275mm
Bezel colour and finish     black, matte

TOUCH
Touch technology     bonded PCAP
Touch points     10 (HID, only with supported OS)
Touch method     stylus, finger, glove
Touch interface     USB
Supported operating systems     All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.

INTERFACES / CONNECTORS / CONTROLS
Digital signal input     HDMI x1
DisplayPort x1
Audio output     Speakers 2 x 2W
HDCP     yes
USB HUB     x2 (USB3.2 Gen 1 (5Gbps, 5V, 900mA))

FEATURES
Extra     Optical bonding PCAP, metal housing, anti fingerprint coating, waterproof Touch function
Glass thickness     3.6mm
Glass hardness     7H
60950 Ball drop test     yes
Water and dust protection     IP1X (front)
Housing (bezel)     metal
OSD key lock     yes

GENERAL
OSD languages     EN, DE, FR, CN, RU, JP, NL, PL
Control buttons     Menu, Scroll up/ Eco, Scroll down/ Volume, Enter/ Input select, Power
User controls     Picture adjust (brightness, contrast, i-Style color, adv. contrast, ECO mode, OD, X-Res), color settings (gamma, RGB range, color. temp.), image settings (video mode adjust, blue light reducer, sharp & soft), OSD (H. pos., V. pos., time, background, rotate, language, display information), extra (reset, DDC/CI, signal select, volume, mute, led, opening logo, touch switch)
Blue light reducer     yes
Plug&Play     DDC2B

MECHANICAL
Orientation     landscape, portrait, face-up
Fanless design     yes
VESA mounting     100 x 100mm

POWER MANAGEMENT
Power supply unit     internal
Power supply     AC 100 - 240V, 50/60Hz
Power usage     22W typical, 1.5W stand by, 0.3W off mode

SUSTAINABILITY
Regulations     CE, TÜV-Bauart, EAC, RoHS support, ErP, WEEE, REACH, UKCA
Energy efficiency class (Regulation (EU) 2017/1369)     E
REACH SVHC     above 0.1%: Lead

DIMENSIONS / WEIGHT
Product dimensions W x H x D     561.5 x 366 x 239.5mm
Box dimensions W x H x D     650 x 430 x 155mm
Weight (without box)     8.2kg
Weight (with box)     10kg
