Сървър HPE ProLiant DL320 Gen11 (P57685-421), осемядрен Sapphire Rapids Intel Xeon Bronze 3408U 1.8/1.9GHz, 16GB DDR5 ECC RDIMM, без твърд диск, 2x Gigabit Ethernet, 3x USB 3.2 Gen 1 Type-A, No OS, 1000W PSU Titanium

HPE ProLiant DL320 Gen11
P57685-421

Specs:
Product Form Factor Rack-mountable - 1U
Embedded Security Trusted Platform Module (TPM 2.0) Security Chip
Server Scalability 1-way
Hot-Swap Bays Qty 4

Processor / Chipset
CPU Intel Xeon Bronze 3408U
Clock Speed 1.8 GHz
Max Turbo Speed 1.9 GHz
Number of Cores 8-core
CPU Qty 1
Max CPU Qty 1
CPU Upgradability Upgradable
Chipset Type Intel C741

Cache Memory
Installed Size L3 Cache - 22.5 MB
Cache Per Processor 22.5 MB

RAM
Installed Size 16 GB (installed) / 2.04 TB (max)
Technology DDR5 SDRAM - Advanced ECC
Effective Memory Speed 4000MT/s
Rated Memory Speed 4800MT/s
Form Factor DIMM 288-pin
Slots 16 (Total) / 15 (empty)
Features Registered, 8-channel memory architecture, HPE SmartMemory
Configuration Features 1x 16 GB

Hard Drive
Type No HDD

Storage Controller
Type 1x RAID
Channel Qty 8

Optical Storage
Type No optical drive

Graphics Controller
Video Memory 16 MB
Video Interfaces VGA

Networking
Ethernet Ports 2x Gigabit Ethernet
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol SNMP 3, IPMI 2.0
Features Wake on LAN (WoL), ACPI support, PXE support

Expansion / Connectivity
Bays
4x hot-swap 3.5" LFF

Slots
2x PCIe 5.0 x16 - full-length, full-height (x16 mode)
1x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)

Interfaces
1x HPE iLO (1 in front) (service port)
3x USB 3.2 Gen 1 (1 front, 2 rear)
1x USB 2.0
1x VGA
2x LAN (Gigabit Ethernet)

Power
Device Type Power supply - hot-plug
Power Redundancy Optional
Power Redundancy Scheme 1+1 (with optional power supply)
Installed Qty 1
Max Supported Qty 2
Voltage Required AC 200/240 V
Power Provided 1000 Watt
80 PLUS Certification 80 PLUS Titanium
Operating System / Software
OS Provided No operating system
OS Certified SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, CentOS, VMware ESXi, Oracle Linux, Canonical Ubuntu, Oracle VM, Citrix

Sustainability Information
ENERGY STAR Certified Yes

Dimensions & Weight
Width 43.46 cm
Depth 66.46 cm
Height 4.28 cm
Weight 13.2 kg

Environmental Parameters
Min Operating Temperature 10 °C
Max Operating Temperature 35 °C
Humidity Range Operating 8 - 90% RH (non-condensing)
