SI Суич HP 5120-24G-PoE+ (370W), 24 ports 1000Mbps

Сигурност Access control lists (ACLs), Secure management access, Secure FTP, Guest VLAN, Port isolation, STP BPDU port protection, STP root guard, DHCP protection, IP source guard, RADIUS/HWTACACS, Port security, MAC-based authentication
Други 1 RJ-45 serial console port
Захранване Input voltage: 100-240 VAC; Maximum power rating: 832 W (With AC input, the maximum power consumption is 523 W)
MAC адреси 8000 MAC address table size
Управление Friendly port names, Remote configuration and management, Manager and operator privilege levels, Secure Web GUI, Dual flash images, SNMPv1, v2c, and v3, Remote monitoring (RMON), IEEE 802.1AB Link Layer Discovery Protocol (LLDP), DLDP
Памет (Flash, RAM) Flash Memory: 128 MB; RAM: 128 MB SDRAM
VLAN (брой, стандарти) Support IEEE 802.1Q with 4,094 simultaneous VLAN IDs
Размери, mm 440 x 420 x 43.6 mm, 1U height
Stackable No
Суич, тип Fixed Port
Общ брой портове 28
Основни портове, тип 24x10/100/1000Base-T
Power Over Ethernet (PoE) IEEE 802.3at and IEEE 802.3af; PoE power: 720 W; With AC input, the maximum power consumption is 370 W for PoE.
Uplink портове 4 dual personality
Свободни (10GB) слотове No
Fans yes; use variable-speed fans to improve energy efficiency
Routing Layer 3 Lite
Капацитет за маршрутизиране/превключване, Gbps 56 Gbps
Пропускателна способност, Mpps 41.7 Mpps

QoS Advanced classifier-based QoS: classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; Powerful QoS feature - supports the following congestion actions: strict priority (SP) queuing, SDWRR, and SP+SDWRR; Broadcast control

L3 мрежови стандарти Static IP routing: provides manually configured routing for both IPv4 and IPv6 networks; Routing table size: 32 entries (IPv4)

IPv6 functionality IPv6 host, Dual stack (IPv4 and IPv6 using BIS), IPv6 ACL

L2 мрежови стандарти IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3z
