Кутия Fractal Design Define R5 Black, ATX/Micro-ATX/Mini-ITX, 2x USB 3.0, черна, без захранване

Fractal Design Define R5 Black
FD-CA-DEF-R5-BK

Specifications

ATX, Micro ATX, Mini ITX motherboard compatibility
7 expansion slots
2 - 5.25" bays (removable)
8 - 3.5" HDD positions (can also accommodate 2.5" units); 2 - 2.5" dedicated SSD unit positions
4 - ModuVent™ plates - three in the top and one in the side
9 - fan positions (2 Fractal Design Dynamic GP14 140mm fans included)
Filtered fan slots in the front and bottom
CPU coolers up to 180mm in height
ATX PSUs up to 190/170 mm with a bottom 120/140mm fan installed; when not using any bottom fan location longer PSUs up to 300mm can be used
Graphics cards up to 310 mm in length with the top HDD cage installed; with the top cage removed, graphics cards up to 440 mm in length may be installed
20 - 35 mm of space for cable routing behind the motherboard plate
Velcro straps included for easy cable management
Front door can switch opening direction via dual mounting system
Left side panel features Quick Release System for easy access and provides a secure closure of side panel
Right side panel features smart captive thumbscrews so no thumbscrews are lost
Colours available: Black, Titanium (black case, titanium front panel), White
Case dimensions (WxHxD): 232 x 451 x 521mm
Case dimensions - with feet/screws/protrusions: 232 x 462 x 531mm
Net weight: 10.7 kg
Package dimensions (WxHxD): 327 x 615 x 540mm
Package weight: 12.5 kg

Cooling system

Front: 2 – 120/140 mm fans (included is 1 Fractal Design Dynamic GP14 fan, 1000 RPM speed)
Rear: 1 – 120/140 mm fan (included is 1 Fractal Design Dynamic GP14 fan, 1000 RPM speed)
Top: 3 - 120/140 mm fan (not included)
Bottom: 2 – 120/140 mm fan (not included)
Side: 1 – 120/140 mm fan (not included)
Fan controller: 3 step fan controller for up to 3 fans
Dust filters: Bottom and front intakes

Water cooling compatibility

Front – 360, 280, 240, 140 and 120 mm radiators of all thicknesses (requires removal of drive bays)
Top – 420, 360, 280, 240, 140 and 120 mm radiators. (A thickness limitation of 55mm for both radiator + fan applies on 420, 280 and 140 mm radiators) (420 and 360 mm radiators require removal of the ODD bay)
Bottom – 120 or 240 mm radiator (Use of radiators in the bottom position limits the PSU length to 165 mm)
Rear – 120 or 140 mm radiator

Front interface

2 USB 3.0 + 2 USB 2.0
Audio in/out
Power button with LED (blue)
HDD activity LED (blue)
Reset butto

JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
