Define 7 XL
Re-defining capacity.
The Define 7 XL sets a new standard for what you should expect from a fulltower case in terms of modularity, flexibility and ease of use.With its dual-layout interior, industrial sound damping and massively versatilelayout supporting the largest E-ATX and enterprise boards, multi-GPU setups,outlandish water loops, and almost two dozen storage devices (in Storagelayout), you’ll be hard pressed to find a limit to what you can do with yourbuild in the Define 7 X
Keyfeatures
-
Spacious, extensively adaptable dual-layout interior easily accommodates large motherboards up to E-ATX and SSI-EEB
-
Mount up to 18 HDD/SSDs plus five SSDs in the Storage Layout (6 HDD/SSD trays + 2 SSD brackets + 2 multi-brackets inc
-
Use the Open Layout for more headroom and gargantuan water-cooling with radiators up to 480 mm in front or top and 28
-
Two 5.25” ODD bays can be converted to an additional front fan mount with filtered louver covering
-
Silence-optimized construction with industrial sound-damped front, top, and side panels
-
Top panel effortlessly swaps from sound damped solid steel to filtered ventilation
-
New chassis design opens up to fully expose the case interior on three sides for totally unhindered installation and
-
Anodized aluminum front panel with reversible dual-handed hinges opens and closes easily with magnetic latching
-
Outstanding cooling capacity with a total of 9 x 140 mm or 11 x 120 mm fan mounts and three preinstalled Dynamic X2 G
-
Versatile new multi-brackets convert any unused fan position to an HDD, SSD or pump mount
-
Three vertical GPU slots for use with the Flex VRC-25 PCIe riser, available separately
-
Five front USB ports including one USB 3.1 Gen 2 Type-C with fast charging support and speeds up to 10Gbps
-
Ultra-slim Nexus+ 2 fan hub connects up to three PWM fans and six 3-pin fans directly in line with cable channels along the edge of the case
-
Sturdy new HDD cage design with vibration damped trays
-
Tool-less, top-latching panels allow quick access while preventing accidental drops
-
Bridgeless expansion slots ensure obstruction-free connections for easier installation and hookup
-
Ventilated PSU shroud with two-part removable cover
-
Easy-to-clean high airflow nylon filters on the front, top, and base with full PSU coverage and convenient front access
-
13 pass-through holes with ten rubber grommets and two removable covers make for clean cable routing regardless of motherboard size
-
Dachable PSU cable shield and integrated cable guides with Velcro straps further simplify cable management behind the board
General Specifications
3.5"/2.5" drive mounts: 6 + 2 included, 18 positions total
Dedicated 2.5" drive mounts: 2 trays included, 5 positions total
5.25” drive mounts: 2
Expansion slots: 9 + 3
Motherboard compatibility: E-ATX/ATX/mATX/mITX/EE-ATX/SSI-CEB/SSI-EEB
Power supply type: ATX
Front interface: 1 x USB 3.1 Gen 2 Type-C, 2 x USB 3.0, 2 x USB 2.0,
Audio I/O, Power button, Reset button
Total fan mounts: 11 x 120 mm or 9 x 140 mm
Front fan: 4 x 120 mm or 3 x 140 mm, (2 x Dynamic X2 GP-14 included)
Top fan: 4 x 120 mm or 3 x 140 mm
Rear fan: 1 x 120/140 mm, (1 x Dynamic X2 GP-14 included)
Bottom fan: 2 x 120/140 mm
Dust filters: Top, 2 x Front, Bottom + PSU
Front radiator: Up to 480/420 mm
Top radiator: Up to 480/420 mm
Rear radiator: 120 mm
Bottom radiator: Up to 240/280 mm
PSU max length: 250 mm (both HDD cages installed)
GPU max length: Storage layout: 359 mm
CPU cooler max height: 185 mm
Cable routing space: 30 mm
Cable routing grommets: Yes
Fixed velcro straps: Yes
Tool-less push-to-lock: Both side panels and top
Captive thumbscrews: HDD brackets, SSD brackets, PSU bracket
Left side panel: Industrial sound-damped steel or Tempered glass
Right side panel: Industrial sound-damped steel
Case dimensions (LxWxH): 604 x 240 x 566 mm
Case dimensions w/o feet/protrusions/screws: 590 x 240 x 548 mm
Net weight: TG: 16.64 kg/Solid: 16.53 kg
Package dimensions (LxWxH): 646 x 357 x 708 mm
Gross weight: TG: 18.84 kg/Solid: 18.73 k
