The EVGA SuperNOVA G1+ Power Supplies have arrived. Launched in May 2014, the EVGA SuperNOVA G1 power supplies have been among the longest-lasting and best-performing power supplies on the market. Despite only a few changes over the years, it's only fitting that these are due for an upgrade. Enter the G1+, the new and improved fully-modular power supply line-up from EVGA with an 80+ Gold Efficiency rating.
Compared to the EVGA SuperNOVA G1 power supplies, the G1+ are up to 20mm shorter, feature 100% Japanese capacitors, are up to 20% quieter, have much tighter 12v. load regulation, and have a superior fluid-dynamic bearing fan. Combining a full set of current, voltage, and temperature protections with EVGA's World Leading 10-Year Warranty, the EVGA SuperNOVA G1+ power supplies set the new Gold standard for performance and value.
Features:
-
Unbeatable EVGA 10 Year Warranty and unparalleled EVGA Customer Support
-
80 PLUS Gold certified, with 90% (115VAC) / 92% (220VAC~240VAC) efficiency or higher under typical loads
-
Highest quality Japanese brand capacitors ensure long-term reliability
-
Fully Modular to reduce clutter and improve airflow
-
NVIDIA SLI & AMD Crossfire Ready
-
Double Ball Bearing fan for exceptional reliability and quiet operation
-
Heavy-duty protections, including OVP (Over Voltage Protection), UVP (Under Voltage Protection), OCP (Over Current Protection), OPP (Over Power Protection), SCP (Short Circuit Protection), and OTP (Over Temperature Protection)
Specifications:
Cable Length
| ATX Cable | 1x 600mm |
| EPS Cable | 2x 750mm |
| PCIE Cable | 4x 750mm, 6x 750mm, 900mm |
| SATA Cable | 4x 550mm, 650mm, 750mm, 850mm, 950mm |
| Four-Pin Peripheral Cable | 2x 550mm, 650mm, 750mm, 850mm |
| Floppy Adapter | 1x 100mm |
| AC Power | 1x 1530mm |
| Modular Cable Type | Full |
| Molex to FDD | 1x |
Connector Quantity
| 24 Pin ATX | 1x |
| EPS (CPU) | 2x 8pin (4+4 |
| PCIE | 16x 8pin (6+2) |
| SATA | 18x |
| Four-Pin Peripheral | 8x |
| Floppy | 2x |
Power Specs
| AC Input | 200 - 240 VAC, 9A, 50 - 60 Hz | ||||
| Rail | +3.3V | +5V | +12V | +5Vsb | -12V |
| Max Output | 25A | 25A | 166.6A | 4A | 0.5A |
| 166.6A | |||||
| 150W | 1999.2W | 6W | 20W | ||
| Total | 2000W @ +50C | ||||
Additional Details
| Operating Temperature | 0° to 50° C |
| Japanese Capacitors | 100% |
| ECO Mode | Yes |
| MTBF | 100,000 Hours |
| Net Weight | 7 lbs |
| Size | 85mm (H) x 150mm (W) x 220mm (L) |
| Approvals | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS Compliance with ErP Lot 6 2013 Requirement |
| Fan Size / Bearing | 140mm 2-Ball Bearing |
