EATON UPS Ellipse PRO 650 FR ELP650FR
EATON UPS Ellipse PRO 650 FR ELP650FREATON UPS Ellipse PRO 650 FR ELP650FREATON UPS Ellipse PRO 650 FR ELP650FREATON UPS Ellipse PRO 650 FR ELP650FR
ОписаниеХарактеристикиРевюта / Въпроси
EATON UPS Ellipse PRO 650 FR rack/tower - AC 230 V - 400 Watt - 650 VA 4 Output FR - 2U - 19inch

General
Device Type: UPS - external
Height (Rack Units): 2U
Rack Size: 19"

Power Device
UPS Technology: Line interactive
Input Voltage: AC 230 V
Input Voltage Range: AC 165 - 285 V
Input Voltage Range (Adjustable): AC 150 - 285 V
Frequency Provided: 50/60 Hz
Frequency Required: 50/60 Hz
Input Connectors: 1 x power IEC 60320 C14
Power Output Connectors Details
3 x power CEE 7/5 (UPS and surge)
1 x power CEE 7/5 (surge)
Output Voltage AC 220/230/240 V + 15% / - 20% - 50/60 Hz
Power Capacity 400 Watt / 650 VA
Dataline Surge Protection: Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line
Surge Suppression: Yes
Circuit Protection: Circuit breaker

Battery
Technology: Lead Acid
Capacity: 7 Ah
Run Time (Up To)
9 min at half load
5 min at 70% load

Networking
Remote Management Interface: USB

Expansion / Connectivity
Interfaces: 1 x management (USB) - 4 pin USB Type B

Miscellaneous
Cables Included: USB cable - external
Rack Mounting Kit: Optional
Features: Wall mountable, LCD display, Automatic Voltage Regulation (AVR), deep discharge protection, cold-start function, EcoControl Master/Control outlets
Compliant Standards: CB, IEC 62040-1-1, IEC 62040-2, IEC 61643-1, EN 62040-1-1, EN 62040-2

Dimensions & Weight
Width: 8.2 cm
Depth: 28.5 cm
Height: 26 cm
Weight: 6.6 kg



    Виж още UPS Eaton
    Виж всички UPS в категорията
    Технически характеристики
    Изходяща мощност:  650 VA
    Тип:  Line Interactive
    Формфактор:  Tower
