Дънна платка Gigabyte A620M Gaming X, A620, AM5, DDR5, PCI-E 4.0 (HDMI/DP), 1x M.2, 4x SATA 6Gb/s, 1x USB 3.2 Gen 2 Type-A, 1x USB 3.2 Gen 1 Type-C, Micro ATX





AMD Ryzen™ 7000 Series Processors

AMD A620



Support for DDR5 6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/4800/4400 MT/s memory modules

4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory

Dual channel memory architecture

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for AMD EXtended Profiles for Overclocking (AMD EXPO™) and Extreme Memory Profile (XMP) memory modules

(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to "Memory Support List" for more information.)



1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz

1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz



Realtek® Audio CODEC

High Definition Audio

2/4/5.1/7.1-channel



Realtek® GbE LAN chip (1 Gbps/100 Mbps)



1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)



1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1



1 x M.2 connector (Socket 3, M key, type 2580 PCIe 4.0 x4/x2 SSD support)



4 x SATA 6Gb/s connectors

RAID 0, RAID 1, and RAID 10 support for SATA storage devices



1 x USB 3.2 Gen 2 Type-A port (red) on the back panel

1 x USB Type-C® port on the back panel, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 1 port on the back panel



1 x USB Type-C® port with USB 3.2 Gen 1 support, available through the internal USB header

3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header)

4 x USB 2.0/1.1 ports (2 ports on the back panel, 2 ports available through the internal USB header)



1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

2 x system fan headers

1 x addressable LED strip header

1 x RGB LED strip header

1 x M.2 Socket 3 connector

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB Type-C® header, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 1 header

1 x USB 2.0/1.1 header

1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

1 x Clear CMOS jumper



1 x PS/2 keyboard/mouse port

1 x USB Type-C® port, with USB 3.2 Gen 1 support

1 x USB 3.2 Gen 2 Type-A port (red)

2 x USB 3.2 Gen 1 ports

2 x USB 2.0/1.1 ports

1 x HDMI port

1 x DisplayPort

1 x Q-Flash Plus button

1 x RJ-45 port

3 x audio jacks



iTE® I/O Controller Chip



1 x 256 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Support for Windows 11 64-bit

Support for Windows 10 64-bit



Micro ATX Form Factor

24.4cm x 24.4cm
