Technical Spec
| Motherboards | E-ATX/ATX/M-ATX/Mini-ITX (MAX 305×276mm) |
| Materials | SGCC+Plastic (ABS)+Tempered Glass (Panel thickness: 0.8~1.0mm) |
| Product Dimension (LxWxH) | 530×232×545.5mm |
| Net Weight | 14.34kg |
| Gross Weight | 17.77kg |
| 5.25" Drive Bays | 0 |
| 3.5" Drive Bays | 3 |
| 2.5" Drive Bays | 3+3 |
| I/O Panel | 2×USB3.0 /Audio(HD)×1/Mic×1/Manual Controller for RGB |
| Expansion Slots | 8+2 (2 extra slots for vertical VGA card installation) |
| Cooling Fans Support | Pre-installed: 1×140mm RGB fan at rear, 3×140mm RGB fan at side panel; Optional: Top:3×120mm fan, Front: 3×120mm fan |
| Power Supply Support | ATX PS2 (maximum length: 200mm) |
| CPU Cooler Compatibility | 186mm height limit /Liquid Cooler: 120/240mm or 360mm (Remove HDD cage) Radiator at front; 120/240/360mm Radiator at top; 120/140mm Radiator at rear |
| Graphic Card Clearance | 310mm(Horizontal mounting)/400mm(Vertical mounting) |
| Carton Dimension | 625×335×627mm(L×W×H) |
| Water Block Dimensions | 92.5×93×85mm(L×W×H) |
| Radiator Dimensions | 330×125×28mm(L×W×H) (aluminum material) |
| Fan Dimensions | 140×140×25mm RGB Fan×4pcs |
| Fan Speed | 500±200-1800±10%RPM (4Pin) |
| Fan Air Flow | 90.14 CFM (MAX) Each 140mm Fan |
| Fan Noise Level | 17.6~35.3dB(A) |
| Fan Bearing Type | Hydro Bearing |
| Fan Rated Voltage | 12VDC |
| Fan Rated Current | 0.44±10%A(MAX) Each Fan (Including RGB lights) |
| Fan Power Consumption | 5.28W Each |
| Pump Connector | 3Pin |
| Pump Operating Voltage | 6~13.8VDC |
| Pump Rated Voltage | 12VDC |
| Pump Speed | 2300±10%RPM |
| Pump Current | 0.2A(MAX) |
| Pump Power Consumption | 2.4W |
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Компютърни кутии DeepCool
Виж всички Компютърни кутии в категорията
Технически характеристики
| Захранване: | Не |
|---|---|
| Прозорец: | Да |
| Цвят: | Черен |
