Суич Dahua PFS4226-24ET-240, 24x 10/100 Base-T ports(PoE), 2x 10/100/1000 Base-T Combo ports, 2x 1000 Base-X Combo ports, оптимизиран за системи за видеонаблюдение

Dahua PFS4226-24ET-240

24-портов WEB Managed Layer-2 POE суич оптимизиран за системи за видеонаблюдение.
24 порта х 10/100Base-TX POE, Combo 2 x uplink порт x 10/100/1000Base-T, Combo 2 x Оптичен порт 1000Base-X. POE protocol IEEE802.3af, IEEE802.3at, максимална мощност на порт 1&2: 60W, максимална мощност на порт 3÷24: 30W. Обща мощност 240W, POE-Management & Statistics. Switching Capacity: 8,8Gbps.
Поддържани протоколи: VLAN 802.1Q, STP, RSTP, Port Aggregation: Static link & LACP, Port Mirroring, DCHP-client, Flow Control: Half & Full-duplex, IP & Mac binding, IEEE802.1x, QoS: 802.1P, SNMP V1/2C/3. Extended Mode 250m POE.
Работна температура -10ºC~55ºC.
Вградена гръмозащита 4kV/2kV.
Размери: 440х300х44mm, Rack-mount.
Захранване: AC100~240V.
Съвместими аксесоари: PFT3950, PFT3960, PFT3970.

24-Port PoE Switch
Layer 2 management PoE switch
PoE budget: 240W
Support PoE, PoE+, Hi-PoE
'Orange port' support Hi-PoE, can be used with the PoE extender (PFT1300)
250 meters long distance PoE transmission
PoE management, PoE Setting/Event Statistics/Green PoE
Search and upgrade via ConfigTool
Support Web management
High lightning protection design
Non-blocking video transmission

Technical Specification

Model
DH-PFS4226-24ET-240

Ethernet Port
2*10/100/1000 Base-T (Combo port)
2*1000 Base-X (Combo port)
24*10/100 Base-T (PoE power supply)

PoE Power Consumption
Port1/2 support Hi-PoE (60W), PoE+, PoE
Each power ≤30W
Total≤240W

PoE Protocol
IEEE802.3af, IEEE802.3at, Hi-PoE

Switching Capacity
8.8G

Packet Forwarding Rate
6.55Mpps

Humidity
10%~90%

Power
AC 100~240V

Lightning Protection
Common Mode 4KV
Differential Mode 2V

Working Temperature
﹣10℃~55℃

Weight
3.51kg

Dimension(W×D×H)
440mm x300mm x44mm

Accessories
Model
PFT3950
1.25G 850nm,500m,LC, Multi-mode
PFT3960
1.25G 1310/1550nm,20km,LC, Single-mode
PFT3970
1.25G 1550/1310nm,20km,LC, Single-mode

Service Characteristics
System
Username / password: admin/admin

IP Address :192.168.1.110/24
PoE Budget
240W
MAC Table
4K
VLAN
802.1Q Standard VLAN
Spanning Tree
STP
RSTP
Port Aggregation
Static link aggregation
LACP protocol
Mirroring
Many-to-one port mirroring
DHCP
Support DHCP-Client
Long Distance Mode
"Power & Data" transmission distance up to 250m

Flow Control
Half-duplex based on back pressure type control;
Full duplex based on PAUSE frame

Security Features
IP+MAC binding based on port;
IEEE802.1x port authentication

System Maintenance
One-key recovery
Support the updated packet upload
System log
QoS
High and low priority, WRR
802.1P, DSCP
Support priority according to protocol

Network Management
WEB(http and https protocol)
Support SNMP V1/V2C/V3

PoE Management
PoE setting (real-time port comsumption)
PoE event statistics
Green PoE
