Суич D-Link DGS-1210-28MP, 24x 10/100/1000Base-T ports, 4x 100/1000 SFP uplink ports

D-Link DGS-1210-28MP

24-Port Gigabit Smart Managed PoE Switch with 4 Gigabit RJ45/SFP COMBO ports, 370W PoE Budget

The D-Link DGS-1210 Series Smart Managed Switches are the latest generation of switches to provide increased Power over Ethernet (PoE) output, a range of physical interface types, multiple management interfaces, and advanced Layer 2 features. With all of these features combined, the DGS-1210 Series provides a cost-efficient and flexible solution for expanding any business network.

The DGS-1210 Series switches support 8, 24, or 48 10/100/1000BASE-T ports. Each switch also supports an additional 2 or 4 Gigabit SFP ports for optical connections using multimode or singlemode SFP transceivers.

Сигурност Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, IP-MAC-Port Binding (Smart Binding), 802.1X Port-based Access Control, ARP Spoofing Prevention, Traffic Segmentation, SSH v2, SSL, Port Security
Захранване Internal Universal Power Supply: 100 - 240 VAC, 50/60 Hz
Форм-фактор Desktop/Rackmount
MAC адреси 16000 MAC address table size
Управление Web-based GUI, D-Link Network Assistant Utility, Compact CLI, Telnet Server, TFTP Client, Configurable MDI/MDIX, SNMP v1/v2c/v3, SNMP Trap, Backup/Upgrade firmware, Smart Wizard, Upload/Download Configuration file, RMONv1, Trusted Host, ICMP v6, SNTP

Памет (Flash, RAM) Flash: 32 MB, CPU: 256 MB DDR3
VLAN (брой, стандарти) IEEE 802.1Q; VLAN Group: max. 256 static VLAN groups, max. 4094 VIDs; Asymmetric VLAN; Auto Voice VLAN: max. 10 user defined OUI, max. 8 default OUI; Auto Surveillance VLAN
Stackable No
Суич, тип Fixed Port
Общ брой портове 28
Основни портове, тип 24x10/100/1000Base-T
Power Over Ethernet (PoE) Ports 1 to 24 compliant with 802.3at; PoE Power Budget: 370 W

Uplink портове 4xSFP
Свободни (10GB) слотове No
Fans Low speed: 47.94 dBA, High speed: 52.41 dBA
Routing Layer 3 Lite
Капацитет за маршрутизиране/превключване, Gbps 56 Gbps
Пропускателна способност, Mpps 41.7 Mpps
QoS 802.1p Quality of Service; 8 queues per port; Queue Handling - Strict, Weighted Round Robin (WRR); Bandwidth Control - Port-based (Ingress/Egress, min granularity 10/100/1000 is 64 Kbps); QoS based on: 802.1p Priority Queues, DSCP, ToS, IPv6, TCP/UDP port

L3 мрежови стандарти Static Routing: 64 IPv4 Static Route Entries, 64 IPv4 Static Route Entries
IPv6 functionality IPv6 Ready: Fully IPv6 compatible and ready for enterprise deployment, giving you a head start on the next Internet standards evolution

L2 мрежови стандарти IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1X
Размери (Ш, Д, В), mm 440 x 250 x 44
Опция за монтаж Rackmount
