Discover the Ncore 100 MAX by Cooler Master: a compact, high-performance addition to the MAX series. It offers advanced cooling, power solutions, and a small form factor with anodized aluminum panels. Accommodating up to 3.9 Slot GPU, it ensures compatibility with the latest processors, delivering unparalleled performance without sacrificing design. Experience versatility, compatibility and peak performance with the sleek, space-saving Ncore 100 MAX. Elevate your setup today!
MINIMALIST DESIGN, MAXIMALIST POWER
The Ncore 100 MAX has been designed with a minimalist industrial design that would look right at home in a design studio. The MAX also includes ample ventilation and adjustable space to house enough power to satisfy even the most power-hungry use cases such as gaming and creative works.
Specifications:
Materials - Exterior
Steel, Plastic, Aluminum
Materials - Side Panel
Aluminum
Dimensions (L x W x H)
Normal mode: 155mm x 212mm x 481mm (Incl. Protrusions), Expansion mode: 172mm x 212mm x 481mm (Incl. Protrusions), 155mm x 212mm x 457mm (Excl. Protrusions), 172mm x 212mm x 457mm (Excl. Protrusions)
Volume
15.80L (Normal mode), 17.54L (Expansion mode)
Motherboard Support
ITX
Expansion Slots
3x PCIe Slot mounting
Drive Bays - 2.5" SSD
1
I/O Panel
2x USB 3.2 Gen1 Type A, 1x USB 3.2 Gen2 x 2 Type C, 1x Audio Combo (Audio In / Out 3.5mm)
Included Accessories
1x 240mm PCIe 4.0 x16
Included CPU Cooling Solution
120mm Radiator with 38mm Thickness x 1 (Custom PWM Fan Max. 2400RPM)
Included Power Supply Unit
V SFX Gold 850W ATX 3.0
Pre-installed Fan(s) - Rear
120mm SickleFlow PWM Fan x1 (Max. 1800RPM)
Clearances - CPU Cooler
48mm
Clearances - Power Supply
100mm
Clearances - RAM
48mm
Clearances - Graphics Card
337mm x 62mm x 180mm (Normal, 3.0 Slot thick), 357mm x 79mm x 180mm (Expansion, 3.9 Slot thick), (Maximum space including GPU power connector)
Cable Routing - Behind MB Tray
11mm
Dust Filters
Side panels
Power Supply Support
SFX
