Проектор BenQ SH753+, DLP, Full HD (1920x1080), 5000lm, 13 000:1, HDMI, LAN, VGA

BenQ SH753+




Vivid Clarity in Ambient Environments
SH753+’s 5,000lm high brightness allows presenters and participants to deliver presentations in comfortably lit medium-sized conference rooms, while supporting uncompromised debate, collaboration, note-taking and interaction to achieve the most productive meetings. The high luminance provides professional picture quality for installers to satisfy stringent corporate standards.










Full HD Resolution for Crisp Image Clarity and Increased Content Density
With Full HD (1920 x 1080) native resolution in expanded 16:9 aspect ratio, SH753+ offers subtle details, ultra-sharp readability and highly enhanced display capacity for professional presentations.












Advanced Presentation Modes for Supreme Projection Quality
BenQ’s SH753+ provides several presentation modes that are tailored toward different kinds of presentation venues and content. It includes two advanced presentation modes designed to satisfy the specific needs during different kinds of presentations. The newly released Infographic Mode is perfect for showcasing the text and graphics of infographics in detail due to SH753+’s high color brightness and better color gradation, ensuring more saturated and lively color performance than presentation mode. Additionally, Vivid Mode is designed for supreme color performance during video or image presentation.







Display
Brightness (ANSI lumens)
4300
Native Resolution
1080P (1920x1080)
Native Aspect Ratio
16:9
Contrast Ratio (FOFO)
13000:1
Display Color
30 Bits (1,07 billion colors)
Light Source
Lamp
Light Source Life
Economic 3500 hrs, Normal 2500 hrs, SmartEco 4500 hrs

Optical
Throw Ratio
1.39~2.09
Zoom Ratio
1.5x
Lens
F/#= 2.42 ~2.97, f = 20.7 ~ 31.05mm
Projection Offset (Full-Height)
115%
Keystone Adjustment
2D, Vertical ± 30 degrees; Horizontal ± 30 degrees

Picture Modes
3D, Bright, Infographic, Presentation, sRGB, Vivid

I/O Interface
PC in (D-sub 15pin)
1
Monitor out (D-sub 15pin)
1
Composite Video in (RCA)
1
S-Video in (Mini DIN 4pin)
1
HDMI in
2, HDMI-1 (1.4a/HDCP1.4), HDMI-2 (1.4a/HDCP1.4/MHL)
USB Type A
1, USB Type A-1 (2.0/Power Supply1.5A)
USB Type Mini B
1, USB Type Mini B-1(service/Page up&down)
RS232 in (DB-9pin)
1
DC 12V Trigger (3.5mm Jack)
1

Audio
Audio in (3.5mm Mini Jack)
1
Audio out (3.5mm Mini Jack)
1
Microphone in (Mini Jack)
1

Environment
Operating Temperature
0~40℃
Power Supply
AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V)
365W/110V
Stand-by Power Consumption
<0.5W
Network Stand-by Power Consumption
<2W
Acoustic Noise (Typ./Eco.)(dB)
36/31 dB

Projection System
Projection System
DLP

Optical
Throw Ratio
1.39~2.06
Zoom Ratio
1.5X
Lens Control
F=2.42~2.97, f=20.7~31.05
Keystone Correction
2D, Vertical & Horizontal ± 30 degrees
Projection Size
25.9’’~324.9’’
Projection Offset**
114.9%
