NZXT H510 Flow Matte Black
CA-H52FB-01
This compact mid-tower is an ideal case for high-performance builds and features a perforated front panel for maximized airflow. The H510 is easy to build in and offers flexibility for a variety of ATX parts.
- An optimized perforated top panel delivers increased airflow to your system for improved temperatures
- Iconic cable management bar and uninterrupted tempered-glass side panel
- Cable routing kit with pre-installed channels and straps
- Two Aer F120mm fans and removable filters on all air intakes
- Removable bracket designed for radiators up to 280mm
Key Specs
-
Motherboard Support:Mini-ITX, MicroATX, ATX
-
Enclosure Type:Compact Mid-Tower
-
Case Material:SGCC Steel, Tempered Glass
Dimensions
-
Height:460 mm / 18.11 inches
-
Width:210 mm / 8.26 inches
-
Depth:428 mm / 16.85 inches
-
Weight:6.6 kg / 14.5 lb
Compatibility & Clearance
-
Max CPU Cooler Clearance:165 mm
-
Max GPU Clearance:360 mm
-
Front Fan & Radiator Clearance:60 mm
-
Cable Management:19 - 23 mm
Front I/O Ports
-
USB 3.2 Gen 1 Type-A:1
-
USB 3.2 Gen 2 Type-C:1
-
Headset Audio Jack:1
Expansion Slots
-
Standard:7
-
Vertical:-
Drive Bays
-
2.5":2 + 1
-
3.5":2 + 1
Fan Support
-
Front:2 x 120mm / 2 x 140mm
-
Top:1 x 120mm / 1 x 140mm
-
Rear:1 x 120mm
-
Filters:All air intake
Included Fans
-
Front:1 x Aer F 120mm (Case Version)
-
Top:-
-
Rear:1 x Aer F 120mm (Case Version)
Radiator Support
-
Front:280mm
-
Rear:120mm
Fan Specs
-
Model:Aer F 120mm (Case Version)
-
Speed:1,200 ± 200RPM
-
Airflow:50.42 CFM
-
Noise:28 dBA
-
Bearing:Rifle Bearing
-
Fan Connector:3-pin
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Компютърни кутии NZXT
Виж всички Компютърни кутии в категорията
| Захранване: | Не |
|---|---|
| Прозорец: | Да |
| Цвят: | Черен |
