ASRock B650E PG-ITX WiFi
Tech specs
CPU
Supports AMD Socket AM5 Ryzen 7000 Series Processors
Chipset
AMD B650
Memory
Dual Channel DDR5 Memory Technology
2 x DDR5 DIMM Slots
Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC)
Max. capacity of system memory: 64GB
Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
2 x DDR5 DIMM Slots
Supports DDR5 non-ECC, un-buffered memory up to 6400+(OC)
Max. capacity of system memory: 64GB
Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules
BIOS
256Mb AMI UEFI Legal BIOS with GUI support
Graphics
Integrated AMD RDNA 2 graphics (Actual support may vary by CPU)
1 x eDP 1.4, supports max. resolution up to Full HD 60Hz
1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
1 x eDP 1.4, supports max. resolution up to Full HD 60Hz
1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
Audio
7.1 CH HD Audio with Content Protection (Realtek ALC1220 Audio Codec)
Impedance Sensing on Rear Out port
Individual PCB Layers for R/L Audio Channel
Nahimic Audio
Impedance Sensing on Rear Out port
Individual PCB Layers for R/L Audio Channel
Nahimic Audio
LAN
2.5 Gigabit LAN 10/100/1000/2500 Mb/s
Killer E3100G
Supports Killer LAN Software
Supports Killer DoubleShot Pro
Killer E3100G
Supports Killer LAN Software
Supports Killer DoubleShot Pro
Wireless LAN
802.11ax Wi-Fi 6E Module
Supports IEEE 802.11a/b/g/n/ac/ax
Supports Dual-Band 2x2 160MHz with extended 6GHz band support*
2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
Supports Bluetooth 5.3 + High speed class II
Supports MU-MIMO
Supports Killer LAN Software
Supports Killer DoubleShot Pro
Supports IEEE 802.11a/b/g/n/ac/ax
Supports Dual-Band 2x2 160MHz with extended 6GHz band support*
2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
Supports Bluetooth 5.3 + High speed class II
Supports MU-MIMO
Supports Killer LAN Software
Supports Killer DoubleShot Pro
*Wi-Fi 6E (6GHz band) will be supported by Microsoft Windows 11. The availability will depend on the different regulation status of each country and region. It will be activated (for supported countries) through Windows® Update and software updates once available.
A 6GHz compatible router is required for 6E functionality.
A 6GHz compatible router is required for 6E functionality.
Slots
CPU:
1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module
*Supports NVMe SSD as boot disks
Storage
CPU:
1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode*
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
2 x SATA3 6.0 Gb/s Connectors
*Supports NVMe SSD as boot disks
Supports ASRock U.2 Kit
Supports ASRock U.2 Kit
RAID
Supports RAID 0 and RAID 1 for SATA storage devices
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*
*Requires additional M.2 NVMe expansion cards to support RAID 10
USB
1 x USB 3.2 Gen2x2 Type-C (Front)
1 x USB 3.2 Gen2 Type-C (Rear)
3 x USB 3.2 Gen2 Type-A (Rear)
2 x USB 3.2 Gen1 (Front)
6 x USB 2.0 (4 Rear, 2 Front)
1 x USB 3.2 Gen2 Type-C (Rear)
3 x USB 3.2 Gen2 Type-A (Rear)
2 x USB 3.2 Gen1 (Front)
6 x USB 2.0 (4 Rear, 2 Front)
*All USB ports support ESD Protection
Connector
1 x eDP Signal Connector
2 x Addressable LED Headers*
1 x CPU Fan Connector (4-pin)**
1 x CPU/Water Pump Fan (M.2 Fan) Connector (4-pin) (Smart Fan Speed Control)***
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
1 x Front Panel Audio Connector (15μ Gold Audio Connector)
1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (ReDriver)
2 x Addressable LED Headers*
1 x CPU Fan Connector (4-pin)**
1 x CPU/Water Pump Fan (M.2 Fan) Connector (4-pin) (Smart Fan Speed Control)***
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****
1 x 24 pin ATX Power Connector (Hi-Density Power Connector)
1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
1 x Front Panel Audio Connector (15μ Gold Audio Connector)
1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) (ReDriver)
*Support in total up to 5V/3A, 15W LED Strip
**CPU_FAN1 supports the fan power up to 1A (12W).
***CPU_FAN2/WP (M.2 fan connector) supports the fan power up to 2A (24W).
CPU_FAN2/WP (M.2 fan connector) is connected to the attached fan Cable of ASRock Blazing M.2 Gen5 Fan Heatsink pre-installed on M2_1 socket.
****CHA_FAN1/WP supports the fan power up to 2A (24W).
CPU_FAN2/WP (M.2 fan connector) and CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
**CPU_FAN1 supports the fan power up to 1A (12W).
***CPU_FAN2/WP (M.2 fan connector) supports the fan power up to 2A (24W).
CPU_FAN2/WP (M.2 fan connector) is connected to the attached fan Cable of ASRock Blazing M.2 Gen5 Fan Heatsink pre-installed on M2_1 socket.
****CHA_FAN1/WP supports the fan power up to 2A (24W).
CPU_FAN2/WP (M.2 fan connector) and CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
Rear Panel I/O
2 x Antenna Ports
1 x HDMI Port
1 x Optical SPDIF Out Port
3 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (USB32_23 are Lightning Gaming Ports.)
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)
4 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x Line Out Jack (Gold Audio Jack)
1 x Microphone Input Jack (Gold Audio Jack)
1 x HDMI Port
1 x Optical SPDIF Out Port
3 x USB 3.2 Gen2 Type-A Ports (10 Gb/s) (USB32_23 are Lightning Gaming Ports.)
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)
4 x USB 2.0 Ports
1 x RJ-45 LAN Port
1 x Line Out Jack (Gold Audio Jack)
1 x Microphone Input Jack (Gold Audio Jack)
Form Factor
Mini-ITX Form Factor
17.0 cm x 17.0 cm
OS
Microsoft Windows 10 64-bit / 11 64-bit
Виж още Дънни платки за AMD процесори ASRock
Виж всички Дънни платки за AMD процесори в категорията
Технически характеристики
| Процесор сокет: | AM5 |
|---|---|
| Чипсет: | B650 |
| Поддържана памет: | DDR5 |
| Брой слотове за RAM памет: | 2 |
| Storage интерфейси: | SATA 6Gbit/s, M.2 |
| RAID: | Да |
| Безжични мрежи: | 802.11ax |
| Bluetooth: | Не |
| Видео слот: | PCI-E |
| Multi-Graphics технология: | Няма |
| Видео изход: | DP HDMI |
| Форм фактор: | Mini-ITX |
| Видеокарта: | Вградена |
