ASUS EKWB GeForce RTX™ 3090 24GB GDDR6X is a smart collaboration between ASUS and EK®
- NVIDIA Ampere Streaming Multiprocessors: The building blocks for the world’s fastest, most efficient GPU, the all-new Ampere SM brings 2X the FP32 throughput and improved power efficiency.
- 2nd Generation RT Cores: Experience 2X the throughput of 1st gen RT Cores, plus concurrent RT and shading for a whole new level of ray tracing performance.
- 3rd Generation Tensor Cores: Get up to 2X the throughput with structural sparsity and advanced AI algorithms such as DLSS. Now with support for up to 8K resolution, these cores deliver a massive boost in game performance and all-new AI capabilities.
- Features an EK® Water Block designed for custom loops.
- A protective backplate prevents PCB flex and trace damage.
- A stainless steel bracket is harder and more resistant to corrosion.
- A single-slot design fits in small chassis and leaves room for additional PCIe devices.
- Auto-Extreme Technology uses automation to enhance reliability.
.png)
Let it Flow
The ASUS EKWB GeForce RTX™ 3090 cards are the result of collaborative engineering efforts between ASUS and EK®. ASUS Auto-Extreme Technology, along with a metal backplate and customized steel mounting bracket, create a durable foundation for EK®’s full-coverage water block. The entire package takes up just a single slot, bringing the tangible benefits of water cooling to small form factor builds, heavyweight workstations, and showcase rigs.
Specifications:
Graphic Engine
NVIDIA® GeForce RTX™ 3090
Bus Standard
PCI Express 4.0
OpenGL
OpenGL®4.6
Video Memory
24GB GDDR6X
Engine Clock
OC Mode - 1725 MHz (Boost Clock)
Gaming Mode - 1695 MHz (Boost Clock)
Gaming Mode - 1695 MHz (Boost Clock)
CUDA Core
10496
Memory Speed
19.5 Gbps
Memory Interface
384-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1)
Yes x 3 (Native DisplayPort 1.4a)
HDCP Support Yes (2.3)
Yes x 3 (Native DisplayPort 1.4a)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
Yes
Accessories
1 x Collection card
1 x Speedsetup manual
1 x EK Loop Multi Allen Key
2 x EK-Plug G1/4 CSQ Bridge
1 x Speedsetup manual
1 x EK Loop Multi Allen Key
2 x EK-Plug G1/4 CSQ Bridge
Software
ASUS GPU Tweak II & GeForce Game Ready Driver & Studio Driver: please download all software from the support site.
Dimensions
8.5 " x 5.36 " x 0.78 " Inch
21.6 x 13.62 x 1.98 Centimeter
21.6 x 13.62 x 1.98 Centimeter
Recommended PSU
750W
Power Connectors
2 x 8-pin
Slot
1 Slot
JAR Computers може да предложи ремонт/смяна/монтаж в наш сервиз или при партньор.
Виж още Видео карти Asus
Виж всички Видео карти в категорията
Технически характеристики
| GPU производител: | nVidia |
|---|---|
| Капацитет: | 24 GB |
| Тип памет на видеокарта: | GDDR6X |
| Битове (BUS памет): | 384 Bit |
| Интерфейс: | DP HDMI |
