UPS APC EASY UPS BV, 800VA/450W, Line Interactive, Mini Tower

APC EASY UPS BV 800VA, AVR, IEC Outlet, 230V


Technical Specifications

Output

Output power capacity
450Watts / 800VA

Max Configurable Power (Watts)
450Watts / 800VA

Nominal Output Voltage
230V

Output Frequency (not synced)
50/60 Hz +/-1 Hz

Topology
Line Interactive

Waveform type
Stepped approximation to a sinewave

Output Connections
(6) IEC 320 C13 (Battery Backup)

Transfer Time
6ms typical : 10ms maximum


Input

Nominal Input Voltage
230V

Input frequency
50/60 Hz +/- 5 Hz (auto sensing)

Input Connections
IEC-320 C14

Cord Length
1.52meters

Number of Power Cords
1


Batteries & Runtime

Battery type
Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Expected Battery Life (years)
3 - 5

Efficiency
View Efficiency Graph


Communications & Management

Control panel
LED Status display with On Line : On Battery

Audible Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm



Physical
Maximum Height
92mm, 9.25CM

Maximum Width
160mm, 16.05CM

Maximum Depth
305mm, 30.5CM

Net Weight
5.3KG

Shipping weight
5.6KG

Shipping Height
237mm, 23.7CM

Shipping Width
143mm, 14.3CM

Shipping Depth
373mm, 37.3CM


Environmental

Operating Temperature
0 - 40 °C

Operating Relative Humidity
0 - 90 %

Operating Elevation
0-1968.3meters

Audible noise at 1 meter from surface of unit
40.0dBA


Conformance

Approvals
CE

Sustainable Offer Status
RoHS

Compliant
REACH

REACH: Contains No SVHCs
