Монитор AOC 24B3CF2, 23.8" (60.45cm) IPS панел, 100Hz, Full HD, 4ms, 20 000 000:1, 250cd/m2, HDMI, USB, USB-C

AOC 24B3CF2

Sufficiency and efficiency

Compact brilliance with USB-C connectivity and Height-Adjustable Stands for enhanced productivity

	FHD Resolution Want to watch a Blu-ray movie in full quality, enjoy games in high resolution or read crisp text in office applications? Thanks to its Full HD resolution of 1920 x 1080 pixels, this monitor lets you do just that. Whatever you are viewing, with Full HD it will be displayed in rich detail without requiring a high-end graphics card or consuming a lot of your system’s resources.
100Hz Refresh Rate Equip yourself with twice the frame rate of other monitors and say goodbye to image stuttering and blurry motion. With a 100Hz refresh rate every frame is rendered sharply and in smooth succession, so you can line up your shots accurately and appreciate high speed races in all their glory.
	USB-C Simplify the connections with one cable only. The USB-C connection provides DisplayPort Alternate Mode for transferring high-resolution video signals from a notebook to the monitor while simultaneously charging the notebook’s battery from the monitor with USB power delivery. Additionally, the USB 3.1 ensures lightning-fast data transmission, so even transferring a 4K movie can be done in less than one minute.
HDMI HDMI (High-Definition Multimedia Interface) is supported by the current gaming consoles, current GPUs, set-top boxes, supporting the HDCP digital content protection system. HDMI 1.3-1.4b versions support up to 144 Hz refresh rate@1080p and 75 Hz@1440p, while HDMI 2.0-2.0b versions support 240Hz@1080p, 144Hz@1440p and 60 Hz@2160p (4K).

Tech specs:

Screen size (inch)

23.8

Screen size (cm)

60.5

Flat / Curved

Flat

Display hardness

3H

Panel treatment

Antiglare (AG)

Pixel Pitch (mm)

0.2745

Pixels per Inch

93

Panel resolution

1920x1080

Resolution name

FHD

Aspect ratio

16:9

Panel type

IPS

Backlight type

WLED

Max Refresh rate

100 Hz

Response time GtG

4 ms

Response time MPRT

1 ms

Static contrast ratio

1300:1

Dynamic contrast ratio

20M:1

Viewing angle (CR10)

178/178

Display colours

16.7 Million

Brightness in nits

250 cd/m2

OD Response (typical)

4 ms GtG

Panel Haze Value

25%

Panel PPI

93

Local Dimming Zones

Global Dimming

Video Features

Sync technology (VRR)

Adaptive Sync

HDR (High Dynamic Range)

HDR Mode

Blue Light Technology

Low Blue Light

Colour space (sRGB) CIE 1931 %

102.7

Colour space (sRGB) CIE 1976 %

102.5

Colour space (DCI-P3) CIE 1931 %

75.7

Colour space (DCI-P3) CIE 1976 %

81.6

Colour space (Adobe RGB) CIE 1931 %

76.1

Colour space (Adobe RGB) CIE 1976 %

87.8

Colour space (NTSC) CIE 1931 %

72.7

Colour space (NTSC) CIE 1976 %

89.4

Colour space (BT 709) CIE 1931 %

102.7

Colour space (BT 709) CIE 1976 %

102.5

Colour space (BT 2020) CIE 1931 %

54.3

Colour space (BT 2020) CIE 1976 %

59.5

Flicker-Free

Flicker Free

KVM

No

Cabinet information

Bezel type (front)

Ultra Narrow

Bezel Colour (front)

Black

Bezel finishing (front)

Texture

Cabinet colour (backside)

Black

Cabinet finishing (backside)

Texture

Removable stand

✓

Speakers

✓

Speaker power

2 W x 2

Kensington Lock

✓

Vesa wallmount

100x100

I/O define: Connectors on rear cabinet

Vertical insert

VESA Mount screw Spec

M4 x 10

Built-in speakers fire direction

Back fire

VESA Mount Support

Yes

MonitorWebcam

No

Ergonomic information

Tilt

-5 (+3/-0) ~ +23 (-3/+0)

Height adjust (mm)

110mm

Swivel

No

Pivot

No

Sustainability

TCO Certified

No

Carton material

Paper

Carton material print

Water Print (Brown Carton)

Power Consumption

Power supply

Internal

Power source

100 - 240V 50/60Hz

Power consumption on (maximum) in watts

130

Power consumption on (typical) in watts

30

Power consumption standby in watts

0.5

Power consumption off in watts

0.3

Power LED indicator (Operation)

White/Blue

Power LED indicator (Standby)

Orange

Connectivity information

HDMI

HDMI 1.4 x 1

Digital HDCP (HDMI version)

HDCP 1.4

USB-C connectivity

USB-C 3.2 x 1 (DP alt mode, upstream, power delivery up to 65 W)

USB Hub

✓

USB Hub speed

USB 3.2 (Gen 1)

USB downstream ports

2

USB fast charge port

✓

Audio Output

1x Audio out

mini USB (for external keypad)

No

Thunderbolt in

0x

Thunderbolt out

0x

PD for USB C/TBT

USB C1 : PD=65W, PD3.0, 5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A

USB Hub up stream

1 x USB3.2 type C Gen 1, 5 Gbit/s

D-SUB (VGA)

0x

DVI

0x

RJ45

No

Product Dimensions

Product dimensions incl. base (WxHxD) mm

542.4 x (359.9-469.9) x 229.8

Product dimensions excl. base (WxHxD) mm

542.4 x 316.2 x 44.6

Packaging dimensions (WxHxD) mm

613 x 519 x 162

Packaging dimensions (WxHxD) mm (CN)

613 x 519 x 162

Gross weight incl. package (in kg)

7.04

Net weight excl. package (in kg)

4.56

Gross weight incl. package (in kg) (CN)

7.04

Product without stand (kg)

3.04
